Linx Cam is equipped with wireless IP technology and utilizes Wi-Fi, P2P streaming and QR code functions. With just a push of a few buttons, you can easily watch remote real-time video instantly. And with simplified setup steps, the installation can be done quickly and easily as well - no technical skills required.
Linx Cam will be a brilliant partner, helping you care for the aged or for your kids, as well as home and store security. Linx Cam links you and your beloved all the time.
Linx Cam's lens has a rotatable mechanism design which is able to swivel right & left 355 degrees, and tilt up & down a total of 120 degrees.
Swipe on your smartphone and get wider coverage of vision without blind spots.
Low latency encoding based on H.264 compression can minimize the lapsed response time from security service personnel. Also, with high-definition video encoding technology, Linx Cam can capture every detail for security images.
Set the preferred detection area, and Linx Cam will send instant message to your smart device via internet once any movement is detected.
Video settings such as resolution, video flip can be set easily in Linx Cam's app.
Smartphone App | Smartphone OS | iOS 40 and above. Android 2 3 and above |
---|---|---|
ID Enter method | U1D In QR Code Formal | |
APP Function | Auto cruising, Motion Detection, Duplex vocal. Snapshot, remote Video Play back with MICRO SD card, G-MAIL PUSH, AP MODE setting, event log, PTZ control for optical lens, FPS & bps setting of viewing, device manager | |
System | Operating System | Embedded Linux OS |
CPU | ARM 11 | |
Security | AES Encryption, user can change the password | |
Storage | Support up to 32G Micro SD Cards | |
Alarm | Motion detection/emergency button/GPIO < 433MHz or BLE) | |
Camera | Sensor | CMOS 1/6-inch 1 million pixel |
Night Vision | 10 IR LED | |
Lens | 3mm | |
Video | Video Compression | H.264 |
Resolution | HD 720P | VGA | OVGA | |
Maximum Frame Rate | 30fps (Max.) | |
Auto Adjustment | Auto White Balance. Auto Exposure. Automatic Gain | |
Audio | Encode Formats | ADPCM |
Input | Built-in Microphone | |
Output | Built-in Speaker, 3.5mm Audio out | |
Network | Socket | RJ-45 Ethernet slot |
Protocol | TCP/IP, HTTP, TCP, UDP, DHCP, UPnP, P2P | |
Wi-Fi | Wi-Fi 802.11 b/g/n | |
Connection | P2P | |
Others | Power | DC 5V2A |
Working temperature | 32 - 122°F | |
Humidity | 10% - 85% |
Main unit
Wi-Fi Antenna
Power Adapter
Mounting Kit
Network cable
Mounting stand
