Brand | SeaSonic |
---|---|
Series | PRIME Series |
Model | SSR-1000PD |
Type | Intel ATX 12 V |
---|---|
Maximum Power | 1000 W |
Fans | 1 x 135mm Premium Hybrid Fan Control Fluid Dynamic Bearing Fan |
Main Connector | 24Pin |
+12V Rails | Single |
PCI-Express Connector | 8 x 6+2-Pin |
SATA Power Connector | 12 |
Modular | Full Modular |
Efficiency | > 90 %, > 92 % and > 89 % efficiency at 20 %, 50 % and 100 % |
Energy-Efficient | 80 PLUS PLATINUM Certified |
Input Voltage | 100 - 240 V |
Input Frequency Range | 50/60 Hz |
Input Current | 11 - 5.5 A |
Output | +3.3V@25A, +5V@25A, +12V@83A, -12V@0.3A, +5VSB@3A |
MTBF | 150,000 hours |
Approvals | cTUVus, TUV, CB, CCC, BSMI, EAC, Energy Star, RoHS, WEEE, ErP Lot 6, REACH |
Max PSU Length | 170 mm |
Connectors | 1 x Main Power 2 x 4+4-pin CPU 8 x 6+2-pin PCIE 12 x SATA 5 x Peripheral 1 x FDD |
Features | 80 PLUS Platinum Fluid Dyanamic Fan Bearing Premium Hybrid Fan Control Micro Tolerance Load Regulation Cable-free Connection Design Multi-GPU Setup Gold Plated Connectors Protection: OPP, OVP, UVP, OCP, OTP, SCP |
---|
Dimensions | 3.39" x 5.91" x 6.69" |
---|---|
Weight | 9.00 lbs. |
Date First Available | January 20, 2017 |
---|
Pros: Packed well, surrounded by foam and PSU was in a felt bag. Additional pouch supplied for cables that are not being used. Velcro straps were also supplied. Quite, modular, good quality cables, connectors and nice looking.
Cons: Only issue I had was clicking sound from fan on initial power up. Found heavy sheathed cable inside of power supply hitting cooling fan. Open grille and was able to move wire enough to be out of the way of the fan. No further issues. Subtracted one egg for this issue.
Overall Review: Purchased this for a new build. The PSU comes shipped in a felt bag, kind of overkill but at least it wont get marred during shipment. Intake grille looks nice and it is shame to hide it when PSU is mounted fan down.
