Industry Standards: HCNA (ITU G.9954 – HPNA 3.1) / IEEE 802.3 10BASE-T / IEEE 802.3ab 1000BASE-T / IEEE 802.3u 100BASE-TX Max Transfer Distance: 1.5 mi (2.4 km)
Maximum Data Transfer Rate: Up to 112Mbps @ 2,952 ft (900 m) Up to 64Mbps @ 1.5 mi (2.4 km) Speed/distance will vary depending on type/quality of line used (see manual for detailed chart)
MTBF: 57,000 Hours Power Budget: 0 dBm, 12 - 44MHz System and Cable Requirements: 75 Ohm coaxial RG-59, RG-6, RG-7, or RG-11 cable is required
LED Indicators: 1 x Coax Link/Activity 1 x Coax Sync 1 x LAN Link/Activity 1 x Power
Center Tip Polarity: Positive Input Current: 0.36A Input Voltage: 110 - 240 AC Output Current: 1.6 A Output Voltage: 12 DC Plug Type: M Power Consumption < 4W Power Source: 2 AC Adapters Included
Humidity: 10% to 90% RH Operating Temperature: 0 to 50 degree C Storage Temperature: -10 to 70 degree C
Connectors
Connector A
Local Unit Connectors: 1 x RJ-45 Female 2 x Type F (RF Coax) Female
Connector B
Remote Unit Connectors: 1 x RJ-45 Female 2 x Type F (RF Coax) Female
Dimensions & Weight
Dimensions
1.10" x 5.40" x 3.70"
Weight
0.70 lb.
Package Contents
Package Contents
1 x Local Unit 1 x Remote Unit 2 x Universal Power Adapters (NA/EU/UK) or AU in Austrlia 1 x User Manual
