Supermicro SSG-6019P-ACR12L - 12 Bay 3.5" 1U Server - 2x Intel Xeon Gold 6130 2.1GHz 16 Core Processors, 16GB DDR4, AOM-S3224-L, X540, IPMI 2.0, 2x 600 Watt PSUs,

Supermicro SSG-6019P-ACR12L 12-Bay 3.5" 1U Rackmount Server

High-Density Storage in a Compact 1U Form Factor
The Supermicro SSG-6019P-ACR12L is engineered for high-performance, high-density storage applications. With support for up to 12 hot-swap 3.5" SAS3/SATA3 drives and 4 hot-swap 2.5" NVMe/SATA drives, this 1U server is ideal for big data analytics, object storage, and scale-out storage solutions.

Key Features:
Dual Intel® Xeon® Scalable Processors Supports 2nd Gen Intel® Xeon® Scalable processors (Cascade Lake/Skylake) with up to 28 cores per CPU and TDP up to 205W.
12 DIMM Slots Accommodates up to 3TB 3DS ECC DDR4-2933MHz RDIMM/LRDIMM; supports Intel® Optane DC Persistent Memory Modules (DCPMM).
Storage Capacity 12 hot-swap 3.5" SAS3/SATA3 drive bays and 4 hot-swap 2.5" 7mm NVMe/SATA drive bays for flexible storage configurations.
High-Speed Networking Integrated dual 10GBase-T LAN ports via Intel® C622 chipset; includes 1 dedicated IPMI LAN port for remote management.
Expansion Slots Offers 2 PCI-E 3.0 x16 slots, 1 PCI-E 3.0 x8 low-profile slot, and 1 PCI-E 3.0 x4 NVMe M.2 slot for additional expansion needs.
Redundant Power Supply 600W high-efficiency redundant power supplies with PMBus support; Platinum Level certified.
Advanced Cooling Features 6x 40x40x56mm counter-rotating fans to maintain optimal operating temperatures.
Comprehensive Management Includes IPMI 2.0 with virtual media over LAN and KVM-over-LAN support; ASPEED AST2500 BMC for remote management.

Technical Specifications:
Form Factor: 1U Rackmount
Motherboard: Super X11DDW-NT
Chipset: Intel® C622
Memory Capacity: Up to 3TB 3DS ECC DDR4-2933MHz RDIMM/LRDIMM
Storage Controller: Broadcom 3224 SAS3 IT mode controller
Networking: 2x 10GBase-T LAN ports, 1x dedicated IPMI LAN port
Expansion Slots: 2 PCI-E 3.0 x16, 1 PCI-E 3.0 x8 (LP), 1 PCI-E 3.0 x4 NVMe M.2
USB Ports: 4 USB 3.0 ports (rear), 2 USB 2.0 ports (front)
Video Outputs: 1 VGA port via ASPEED AST2500 BMC
Power Supply: 600W Redundant Power Supplies with PMBus
Dimensions (W x H x D): 17.6" x 1.7" x 37.4" (447mm x 43mm x 950mm)
Weight: Net Weight: 65 lbs (29.5 kg); Gross Weight: 80 lbs (36.3 kg)

Why Choose Supermicro?
Supermicro is renowned for delivering high-quality, energy-efficient servers with advanced features and robust support. The SSG-6019P-ACR12L offers the perfect balance of performance, scalability, and reliability for demanding enterprise workloads.

Optimize your data center with the Supermicro SSG-6019P-ACR12L engineered for high-performance computing and enterprise scalability.

Do you need assistance custom configuring a system for a certain use case scenario? No problem, we are here to help and can create a custom listing for you. Contact Us Today at (844) 338-0285

PLEASE NOTE - STOCK PHOTOS ARE SHOWN AND MAY NOT BE THE ACTUAL UNIT SHIPPED.
