Brand | SUPERMICRO |
---|---|
Series | SuperServer |
Model | SYS-1017C-TF |
CPU Type | Intel Xeon E3-1200 & v2 series, 2nd &3 rd Gen Core i3 |
---|---|
CPU Socket | LGA 1155 |
North Bridge | Intel C202 |
---|
Memory Slots | 4 x 240Pin |
---|---|
Max Memory Supported | 32GB |
Memory Type Supported | DDR3 1333/1066/800 |
ECC Supported | Yes |
Serial ATA | 6 x SATA 300 |
---|---|
SATA RAID | RAID 0/1/5/10 |
GPU/VPU | Nuvoton WPCM450RA0BX |
---|
PCI Express | 1x PCI-E 3.0 x8 Full-height Full-length slot |
---|
First LAN | Intel 82579LM |
---|---|
Second LAN | Intel 82574L |
Max. LAN Speed | Dual 10/100/1000Mbps |
Hot-Swap Bays | 4 x 2.5" SATA 300 |
---|
COM | 1 |
---|---|
PS/2 | 2 |
VGA | 1 |
Rear USB | 2 |
RJ45 | 2 x RJ45 LAN ports 1 x RJ45 Dedicated IPMI LAN port |
Max. Power | 330W AC power supply w/ PFC |
---|
Features | Color: Black Processor: Intel Xeon processor E3-1200 & v2 series, Intel 2nd Gen and 3rd Gen Core i3, Intel Pentium and Celeron processors. *Note: BIOS rev. 2.0 or above is needed to support new E3-1200 v2 CPUs, which supports PCI-E 3.0 & DDR3 1600. Intel i5/i7 CPUs are not supported. Intel E3-12x5 series processors which have integrated graphics support are not supported. |
---|
Form Factor | 1U Rackmount |
---|
Dimensions | 21.95" x 16.8" x 1.7" |
---|---|
Weight | 38 lbs. (Gross) |
Date First Available | June 17, 2011 |
---|
