Supermicro SuperServer 5019S-MN4 (SKU Model# SYS-5019S-MN4)
A 1U rackmount server barebone system that's ideal for use in embedded, industrial and security applications. It supports Intel Xeon E3-1200 v6/v5 and Intel 7th/6th Gen Core i3 processors with up to 80W TDP. The four DIMM slots accommodate up to 64GB ECC UDIMM DDR4 memory. This server comes with four hot-swap 3.5" drive bays, quad GbE Ethernet ports, and a 350W 80 PLUS Platinum level power supply that delivers stable and reliable output for the entire system.
To complete this system, you'll need a processor, memory, storage drive and Operating System software.
- Four Hot-swap 3.5" SATA 3 bays w/ RAID
- One PCI-E 3.0 x8 (in x16) AOC slot
- Integrated IPMI 2.0 and KVM with Dedicated LAN
- One VGA, two COM, four USB 3.0, and two USB 2.0
- 350W Platinum Level Power Supply
Integrated Board
X11SSH-LN4F
- Single socket H4 (LGA 1151) supports Intel Xeon processor E3-1200 v6/v5, Intel 7th/6th Gen. Core i3 series, Intel Celeron and Intel Pentium with TDP up to 80W
- Intel C236 chipset
- Up to 64GB Unbuffered ECC UDIMM DDR4 2400MHz; Four DIMM slots
- Expansion slots: one PCI-E 3.0 x8 (in x16), one PCI-E 3.0 x8, one PCI-E 3.0 x4 (in x8)
- Quad GbE LAN with Intel i210-AT
- Eight SATA3 (6Gbps) via C236; RAID 0, 1, 5, 10
- I/O: one VGA, two COM, TPM header
- Support Intel VHD with selected CPU
- Five USB 3.0 (two rear, two via header(s), one Type A), six USB 2.0 (two rear, four via header(s))
- M.2 NGFF connector: PCI-E 3.0 x2, 2280, M-Key, Double Height Connector
Gallery
Please note: images in the description may show a varied configuration or optional parts.
