|Series||Drive X3 AIO|
|Type||Liquid Cooling System|
|Block Compatibility||Intel LGA 2011 / 1156 / 1155 / 1151 / 1150|
AMD TR4 / AM4 / AM3 / AM2 / FM2 / FM1 / 93
|Block Material||C110 copper|
|Pump Bearing||Ceramic shaft, PTFE bearing|
|Radiator Size||127.00 x 375.00 x 28.00 mm|
|Radiator Material||Brass tubes, louvered copper fins|
|Fan Size||3 Fan Slots (120 mm)|
|Fan Dim.||120.00 x 120.00 x 25.00 mm|
|Fan RPM||900+/- 25% - 1800+/- 10% RPM|
|Fan Air Flow||24 - 60 CFM|
|Fan Noise||<16 - <32 dBA|
|Fan Connector||Mini 4-pin|
|Tube Material||Mayhem non-plasticizing PVC tubing|
|Reservoir Capacity||70 ml|
|Coolant Capacity||Pre-filled with Mayhem's non-toxic Pastel Nanofluid Coolant|
|Features||Our design objective for all Swiftech products is always to minimize the operating noise while preserving high thermal performance characteristics. At its lowest speed settings, our Drive X3 AIO cooling systems are virtually inaudible. At its maximum speed, it remains within comfortable audible noise levels.|
With pre-installed fans, and the new Apogee SKF "LT" mounting system, the Drive X3 AIO's are probably the easiest AIO liquid cooling CPU Coolers to install bar none, and are even easier to setup than many high-end air coolers.
Thanks to Apogee SKF Thermal Engine and the copper radiator, high static pressure Helix IRIS 120 mm fans, more powerful DC pump than any other AIO on the market, the Drive X3 AIO coolers deliver superior thermal performance to any comparably sized system on the market.
The Swiftech Drive X series, including the new X3 series differentiate themselves from other AIO's by the ability to be fully customized, and to support additional liquid cooled components such as graphics cards, and/or additional radiator(s).
Speed control of fan and pump are PWM compliant, allowing the Drive X3 series to be recognized and controlled by the motherboard depending on CPU temperature just like any standard CPU cooler. The system includes a PWM controller allowing connection of up to 4 PWM devices (2 to 3 fans depending on model + the pump) which can then be controlled as one by the motherboard.
For lighting control, the IRIS ECO controller also includes 3 more connectors for Swiftech IRIS compatible products, a two-pin connector that can be used for remote control (utilizing the mostly unused reset switch for instance), and finally a small button to change both colors and intensity of the LED's.
Thanks to the location of the integrated pump & reservoir, the overall radiator length is in fact the shortest in its class of all AIO's on the market. This will help to fit the Drive X3 AIO coolers in cases where most other AI
|Date First Available||February 26, 2019|
