Brand | XFX |
---|---|
Model | HD-587A-ZND9 |
Interface | PCI Express 2.0 x16 |
---|
Chipset Manufacturer | ATI |
---|---|
GPU Series | AMD Radeon HD 5000 series |
GPU | Radeon HD 5870 (Cypress XT) |
Core Clock | 875MHz |
Stream Processors | 1600 Stream Processors |
Effective Memory Clock | 1250MHz (5.0Gbps) |
---|---|
Memory Size | 1GB |
Memory Interface | 256-Bit |
Memory Type | GDDR5 |
DirectX | DirectX 11 |
---|
HDMI | 1 x HDMI |
---|---|
DisplayPort | 1 x DisplayPort |
DVI | 2 x DVI |
RAMDAC | 400MHz |
---|---|
Max Resolution | 2560 x 1600 |
Eyefinity Support | Yes |
CrossFireX Support | Yes |
Cooler | With Fan |
System Requirements | Minimum 500 Watt Power Supply Requirement |
Power Connector | 2 x 6-Pin |
Dual-Link DVI Supported | Yes |
HDCP Ready | Yes |
Features | ATI Eyefinity Technology Double Profile |
---|
Card Dimensions (L x H) | 11" x 4.376" x 1.5" |
---|
Package Contents | HD-587A-ZND9 Installation CD with Multi-Language User Guide Quick Installation Guide Driver CD Installation Guide XFX Serial Number Door Hanger 2 x 6-pin to 4-pin power cable CrossFire Bridge DVI to VGA adapter |
---|
Date First Available | November 23, 2009 |
---|
Pros: Worked right out of the box! Had no issues with drivers, stability or size. Took my windows experience rating from 6.9 to 7.3 with this baby! Better stability than my old card.
Cons: Doesn't get up to 100c like my old video card, so the space heater aspect of this PC is ruined.
Overall Review: I sold my 9800GX2 to buy this card, so I upgraded for free, and man was it worth it! 20 FPS on Crysis at Ultra high graphics. Glad to be all ATI/AMD in this case now! Rig Specs: AMD Phenom 9950 Agena 2.6GHz CoolIt CPU Chiller ATI Radeon HD 5870 1GB XXX Edition OCZ Gold 8GB (4 x 2GB) DDR2 800 Western Digital VelociRaptor, 300gb ZALMAN GS1000 SE Black Aluminum / Steel/Plastic(ABS) ATX Mid Tower Computer Case Windows 7 Ultimate 64-bit
