Brand | ZyXEL |
---|---|
Model | ZWUSG20W |
Firewall Type | Gen 3 Application-Layer |
---|---|
Type | Wired + Wireless |
Wireless Technology | IEEE 802.11b/g/n |
Simultaneous Sessions | 6000 |
Throughput | 100 Mbps |
Antenna | 2x2 Antenna |
Ports | 10/100/1000 Interfaces (Copper): 4 x LAN/DMZ, 1 x WAN USB ports: 1 |
LAN Ports | 4 x RJ-45 |
WAN Ports | 1 x RJ-45 |
Wired Speed | 10/100/1000 Mbps |
Encryption Standard | AES/3DES/DES |
VPN | Max. Concurrent IPSec VPN Tunnels: 2 Max. Concurrent SSL VPN Users: 1 Included SSL VPN Users: 1 Virtual Private Network (VPN) ICSA-certified IPSec VPN PPTP, L2TP, IPSec Algorithm: AES/3DES/DES Authentication: SHA-1/MD5 Key management: Manual key/IKE Perfect forward secrecy: (DH group) supprt 1, 2, 5 IPSec NAT traversal Dead peer detection/relay detection PKI (X.509) certificate support Centralize VPN Support Simple wizard support Auto reconnect VPN VPN HA (redundant remote VPN gateways) SSL VPN Clientless secure remote access Support reverse proxy mode and full tunnel mode Unified policy enforcement Supports two-factor authentication Customizable user portal |
Power Input | 100 - 240 V AC, 50 - 60 Hz, 1.2 A |
Features | Firewall ICSA-certified firewall Routing and transparent (bridge) mode Zone-based access control list Stateful packet inspection NAT, PAT Policy base NAT VLAN tagging User-aware policy enforcement SIP/H.323 NAT traversal ALG supports custom ports System Capacity & Performance SPI Firewall Throughput*1: 100 Mbps VPN Throughput (3DES)*2: 30 Mbps*4 Unlimited User Licenses Max. Sessions*6: 6,000 New Session Rate: 900 Max. Concurrent IPSec VPN Tunnels: 2 Max. Concurrent SSL VPN Users: 1 Included SSL VPN Users: 1 Customizable Zone Features Unified Security Gateway for SB (1~5 PC Users) All Gigabit Ethernet interface hardware design High-performance multi-layer threat protection Hybrid VPN (IPSec and SSL) secures connection 3G USB dongle as the backup WAN Application Patrol Application, IM/P2P, stream base media, VoIP granular access control Detail access control of IM (Chat, file transfer, video) Application and IP/P2P bandwidth control User authentication support IM/P2P signature auto update Support more than 15 catalogs IM and P2P Real-Time statistical reports Maximum/guaranteed bandwidth Anti-Spam Zone to zone protection Transparently intercept mail via SMTP/POP3 protocols Blacklist/whitelist support Support DNSBL checking Spam tag support Statistics report System Management Role-based administration Multiple administrator login Multi-Lingual Web GUI (HTTPS/HTTP) Out-of-band management (AUX) Object-based configuration Command line interface (console/web console/SSH/TELNET) SNMP v2c (MIB-II) System configuration rollback Firmware upgrade via FTP/FTP-TLS/Web GUI |
---|
Dimensions | 8.49" x 5.51" x 1.30" |
---|---|
Weight | 0.93 lbs. |
Date First Available | July 09, 2017 |
---|
Pros: As an update to my review posted several months back, the USG20W guy just keeps on trucking, consistently and reliably. Deployed in a home office environment for a client, a small business which really doesn't have the time or the first-hand knowledge to be troubleshooting their networking gear. They just need something that simply works and works well -- and that's exactly what you get with a USG -- provided, of course, that you've updated to a new enough firmware version. This particular unit has been working well on version 3.00(BDR.2)C0 for quite some time now. The only thing that seems to bring it down are occasional power surges, which plague the electrical circuitry of the old house where it's installed. If it were not for the surges, I would expect to see several hundred-day uptimes from this thing between resets - no joke. It's nice to have a mission-critical option at the ready for clients who demand it, but would prefer not to spend into the high hundreds or low thousands for Cisco, Juniper, etc.
Cons: The sheer magnitude of the interface along with its heavy browser weight is often enough to deter many novices -- myself included at first. It *definitely* takes some time getting used to, regardless of your knowledge level, as a first-time user. Once you get the hang of this thing, though, routine actions and deployments become much faster, if not outright automated (settings export/import, command-line, etc).
Overall Review: Reviewers who knock this thing for being too complex or having poor this or that (much of which is completely mitigated with proper setup) could perhaps gain quite a bit of insight by stepping back and understanding the level of device that they're getting themselves into here. This is *not* a consumer-class product series (at least it doesn't appear to be the goal with the USG series). As such, in the world of networking especially, newbies need not apply, or if they do, they must understand and be ready to invest the time into actually learning networking terminology, proper networking setups and how they are achieved with the USG. Once that is done, I would anticipate many 1-egg and 2-egg reviews would turn into 4 or 5-egg reviews.
