NORCO RPC-430 Black 4U Rackmount Super Short Depth 15.25" Server Case 6 External 5.25" Drive Bays

  • 2 x External 5.25" Drive Bays
  • 6 x External 3.5" Drive Bays
  • 2 x 80mm Fans

ICON Loading...
  • Overview
  • Specifications
  • Warranty & Returns
  • Reviews

Norco 4U Rackmount Chassis Drive Bays


NORCO Drive Bays
  • Super short depth, only 15.25 inches
  • 4U rackmount design; meets EIARS-310C standard
  • 2 x 5.25" drive bays, 6 x 3.5 " drive bays
  • Easy drive mounting with screwless rails
  • Support CEB (12" x 10.5"), ATX (12" x 9.6"), Micro ATX (9.6" x 9.6"), ITX (6.7" x 6.7") motherboard
  • 2 x 80mm Rear ball bearing fans for better ventilation
  • 2 x Front USB ports
  • RoHS Compliant
  • Smooth border for safe and comfortable handling


NORCO Drive Bays

Drive Bay Supports six 3.5" drives and two 5.25" drives
Cooling Fan 2 x 80mm ball bearing rear fans
Switch Power ON/OFF x 1, System reset x 1
Indicator Power ON/OFF x 1, HDD x 1, NETWORK X 2
Connector Front USB port x2
Motherboard Compatibility Supports CEB (12" x 10.5"), ATX (12" x 9.6"), Micro ATX (9.6" x 9.6"), ITX (6.7" x 6.7")
Power Supply Options Standard ATX, mini redundant power supply (H x W: 5.91 x 3.31 inches)
Dimensions (W x D x H) 19" x 15.25" x 7" (483 x 387 x 176mm)
Packing Double boxes
Weight 15lbs (6.8kg) (NET) 22lbs (10kg) (GROSS)
Environment Temperature 32 - 131 °F (0 - 55°C) (Operating) -4 - 140 °F (-20 - 60 °C) (Non-Operating)
Relative Humidity 5% to 95%, non-condensing
Vibration (5 - 500Hz) 1Grms (Operating), 2G (Non-Operating)
Shock 10G (with 11ms duration, half sine wave) (Operating), 30G (Non-Operating)


NORCO Drive Bays

Learn more about the Norco Technologies Inc. RPC-430

Warranty, Returns, And Additional Information
  • Warranty
  • Limited Warranty period (parts): 1 year
  • Limited Warranty period (labor): 1 year
  • Read full details

Customer Reviews of the Norco Technologies Inc. RPC-430

Do you own this product? Write a Review

ICON Loading...

Filter Results

  • Ashish T.
  • 3/29/2015 1:18:29 PM
  • Tech Level: High
  • Ownership: 1 day to 1 week

4 out of 5 eggsI pay for SILVER i get SILVER!!

Pros: Value for Money , Robust Built , Space Availability , The screw actually fit where they are . Comes with two Fans at the rear with a 3 Pin Connector (NOT MOLEX) . The HDD,PWR Led connector are labeled , The connectors are not NASA Standards but are pretty reliable and sturdy , as every body says The front panel has changed , It's Left to Right (PWR,RST,LED's, 2 * USB 2.0) . The power buttons have been changed as well . They seem to be mini button switches now with a plastic cover on the outside . No SHARP edges,machining is adequate, Good powder coated matte finish , the Handels can be removed . The grill in the front has a fine filter on the inside, "should" keep dust out . The spacers are tall and comes prefitted with SATA config spacers with extra spacers and adequate number of Mobo screws.The disk quick release plastic trays work like a charm . Theres a small space available in b/w the 5.25 and the 3.5 drive cages , SDD fits in like a charm!! thought the drive is vertical (SATA facing rear) and cannot be fastened to the chassis but stays put . The panel wires are long enough to reach any corner . My Cooler master PSU went in, and I had space on either side so I can have the fan face the left or the right.. unlike proprietary cabinet issues all over

Cons: >>> W R O N G DIMESIONS <<<it is 15.75 deep and not 15.25<<<< it wouldn't fit a 16" depth rack with the cord at the back!! I am generally happy with what I bought.For the money that its worth I wouldn't expect every thing to LEGO together . NEEDS a screw driver and couple of hours to put together. The SATA ports on my Mobo went under the drive rack also with it went along the 24 pin connector.So Wire the MOBO then install it or , Screw out the cover,top plate,front top edge handles , take out the disk rack put in the Mobo ,wire it up then Reverse... . The case folds inwards on the top and the Disk rack is wider hence it cant be just pulled up, it slides FWD. The quick release trays are not very sturdy, but are strong, They get most of there stregth from the HDD cube shape.When using a SDD tray with it , it does remain loose and flimsy but does its job.

Other Thoughts: People Reported non aligning screw>> If it sits well the screws are aligned. The exercise for the Mobo installation is mandated due to the fact that a 4u idea has been fit into a 3u Space . I am not all gaga over it but it definitely is value for money.

Did you find this review helpful? Yes No

  • Jason L.
  • 3/19/2015 9:48:57 PM
  • Tech Level: Somewhat High
  • Ownership: 1 week to 1 month
  • Verified Owner

4 out of 5 eggs

Pros: Good case. No problems with alignment of drives,motherboard etc. No sharp edges etc. Case wiring is long enough. Case has a sturdy feel to it.

Cons: Front button layout is not the same as the photos show. Case fans are worthless. One was DOA. And the other fan is super loud. I have already ordered 2 replacement fans for the case.

Other Thoughts: The change to the front panel buttons isn't bad. Just unexpected. Missing the mute button. And the type of buttons have changed. Deducted one egg for the poor quality 80mm fans.

Did you find this review helpful? Yes No

  • Joseph H.
  • 3/11/2015 5:02:53 PM
  • Tech Level: High
  • Ownership: less than 1 day
  • Verified Owner

4 out of 5 eggsNot a bad case

Pros: I have read all the reviews of this item prior to order it and I must say that I did not have any hole alignment issue with connecting to rails or securing in my cabinet. Everything lined up as it should. Perhaps the issues being had were because of using non norco brand rails. There was one complaint about the buttons being cheap and I must say that the one I received looked different than the one in the photo so I am not sure if the buttons were changed in the design of this case

Cons: none that I have found

Did you find this review helpful? Yes No

  • Michael W.
  • 2/6/2015 12:40:38 PM
  • Tech Level: High
  • Ownership: 1 month to 1 year
  • Verified Owner

3 out of 5 eggsnon-standard galore

Pros: It's a box, and you might be able to mount most things in it.

Cons: There are so many things I found wrong with this box and I found myself modifying it to a great extent.
* The drive bays are very limited, if you think your going to put an SSDD in this thing without issue think again, the spacers you get with SSDD's do not work in these bays plastic holders. The cdrom bay is also a bit quirky to get mounted up.
* It's not square. Another words it's mishapen and even the bolt holes for the covers do not line up correctly. The power supply mounting holes and the motherboard mounts are especially concerning.
*rail mounting is a joke, plan on getting your drill bits out to make this thing work with whatever rail mounting system you found. Just remember it's a full length box so if you found some small 9U server rack to put it in, it won't fit.

Other Thoughts: It's a box. sadly its the cheapest box any budget minded consumer can ask for but as they say you get what you pay for, just be prepared to re-engineer the thing to get what you want.

0 out of 1 people found this review helpful. Did you? Yes No

  • David O.
  • 12/12/2014 10:58:51 AM
  • Tech Level: High
  • Ownership: more than 1 year
  • Verified Owner

4 out of 5 eggs

Pros: Short Depth
good build quality
just about everything in this case can be dissasembled with a screwdriver

Cons: Rackmount screws holes are not perfectly aligned with 19" standard.

I had to drill out the holes to make it fit in my rack. (All my other rack equipment fits no problem so I know it's not my rack.

power and reset button feels a little flimsy. I'm worried about longevity of these switches

Due to short depth, some parts of the motherboard are covered by the Hard Drive trays, so depending on your motherboard configuration, you may need to hook up / install things before mounting the mother board.

Large CPU Coolers may interfere with HDD installation, or may not even fit. You will need to have dimmensions of the cooler to make sure it fits and that air flow is consistant with chassis fans.

In my situation i had Asus z87 Pro and the following had to be installed BEFORE mounting mother board

Memory DIMMS (you may not be able to add/replace RAM without uninstalling motherboard

24-pin Power connector

USB 3.0 Header cable

Power/Reset/LED Header & cables

USB 2.0 7/8

Also I appears that I may have a short in the front panel USB connector, as every time this was connected, my motherboard kept reseting/throwing a code. Once i disconnected it I had no problems.

Other Thoughts: Despite the "cons" I will buy another one of these cases for my next computer.

While a pain to build and install, they are very good quality and an excellent value for what you are getting.

1 out of 1 people found this review helpful. Did you? Yes No

  • Frederick V.
  • 10/18/2014 5:07:27 PM
  • Tech Level: High
  • Ownership: more than 1 year
  • Verified Owner

5 out of 5 eggsGood value for Small Studio

Pros: I purchased these chassis for radio station automation, and digital audio recording. They are very simplistic, and have been providing service now for three years. The internal fans are very quiet, and I have one only 8' away from an announcer and the noise is not picked up by the microphone.

Cons: I wish it had more USB connections on the front, (has only 1), and it would have been nice if there were more LEDs to indicate multiple drives. These are minor complaints. If using a screw gun or power screwdriver, the handles will get in the way.

Other Thoughts: If you are a musician or work in radio broadcasting, this may be a good low cost alternative especially if you run three drives or less on your system.

Did you find this review helpful? Yes No

  • 5/25/2014 4:17:28 PM
  • Tech Level: High
  • Ownership: 1 week to 1 month
  • Verified Owner

5 out of 5 eggs

Pros: Good rackmount case for the $. Easy to work with and a pretty stable case, not flimsy.

Cons: Be careful with that screwdriver, the paint looks very nice but it does scratch a little easier than other cases. I put a small scratch on mine but its enclosed so it wont be noticed. Nothing to deduct an egg for because of my mistake.

Other Thoughts: Some instructions for the rails provided would probably be nice. If you've ever installed a car stereo before its pretty simple to figure out. Stick a rail on the left side of the optical drive and slide it in. Locks pretty well and seems fairly sturdy. To remove the drive just push the clip in on the side of the drive inside the case.

Did you find this review helpful? Yes No

  • Alec K.
  • 1/16/2014 10:41:27 AM
  • Tech Level: High
  • Ownership: 1 month to 1 year
  • Verified Owner

5 out of 5 eggsGreat Case

Pros: great short rackmount case, sturdy, very quiet, nice tiny power&reset buttons (won't hit accidentally), 4 lan activity leds.

Cons: get ready to disassemble the whole case to get the motherboard in if you're using a large cpu cooler, or if you're installing 5.25in drives.

Did you find this review helpful? Yes No

  • David C.
  • 1/14/2014 10:41:07 PM
  • Tech Level: High
  • Ownership: 1 week to 1 month
  • Verified Owner

3 out of 5 eggsOk, but not great.

Pros: * The short depth works well for small home racks (my intended use).
* Plenty of 3.5" bays (6).
* Front panel cables are sufficiently long to reach motherboard headers anywhere.
* Back panel fans are quiet (somewhere in the 20 dB range).
* Screw packs are labeled -- this may seem minor, but it saves a lot of installation headache when you're not trying to distinguish between motherboard mounts and power supply screws.
* Inexpensive.

Cons: The manufacturer had to cut a lot of corners to hit this price point, and it shows:

* Fair to poor mechanical tolerances. Trying to get the holes to line up after taking the drive tray out is a balancing act as you try to apply force in odd directions to get the screws in. (I've seen worse, but this is definitely below average.)
* Screws are made of soft metal -- very easy to strip.
* Screws are too short -- hard to get into the case especially with the poor tolerances noted above.
* Poor finish. As soon as you start removing screws, flecks of paint start coming off and reveal bare metal.
* Plastic handles. You will need to remove the handles to get at the drive trays. However, the screws which hold them in dig into the plastic itself (like how most case fans are mounted); each time you remove the screws, a bit of the plastic comes off. There are a limited number of times you can take the handles off before the screws won't be able to hold.
* Odd rackmount hole configuration. There are two holes in the center on each side; if you put a lot of equipment inside, this will put a lot of stress on the rackmount rails at that spot. I'd expect at least four holes per side (which two at either end) for better weight distribution.
* Installing 3.5" drives requires you to unscrew a centerpiece holder, remove a flimsy plastic carrier (which catches on every corner; very high risk of breakage in this step), seat the HDD into the carrier, then reinstall the carrier and centerpiece. I would've preferred the standard screws here.
* Rear slot covers are not replaceable.
* Installing expansion cards requires you to push the card in partway (the back edge won't seat correctly at first), then use a screwdriver to force the lip back into the case.

Other Thoughts: My main goal was to get a short depth rackmount case (small 16U home networking rack), so this rack ended up being adequate. I would have gladly paid $20 more to have some of the cut-corners remedied -- especially the poor mechanical tolerances, finish, and soft screws.

2 out of 2 people found this review helpful. Did you? Yes No

  • 1/1/2014 9:30:49 AM
  • Tech Level: High
  • Ownership: 1 week to 1 month
  • Verified Owner

5 out of 5 eggsNew revision fixes a lot of my old complaints

Pros: I bought a new batch of these at the end of Nov-2013 and Norco has changed the design a bit since my Aug 2013 review.

They now correctly advertise up to 12x10.5 board support and not EATX.

The front panel is completely changed with working LEDs for: power, HDD, three LANs, and an alert. Also, two USB 2.0 ports with a standard 9-pin plug. And it all works this time!

Cons: Paint quality on my new batch wasn’t as good. Came out of boxes with some light scratches and such already. Not really too big of deal for something that I’ll never look at and is in this price range. (I would subtract eggs from a more expensive chassis with this sort of paint quality)

Strangely, one of the USB ports is a blue USB 3.0 plug. But, they don’t have the cable to plug in to a USB 3.0 header on a mobo. Works fine as dual 2.0 ports though.

Many fewer holes in the side of the case now. I guess if you’re using Norco’s rails this shouldn’t be an issue but if you are doing anything creative you might have a harder time.

Other Thoughts: Too bad Newegg doesn’t let you upload pics in a review so I could show changes.

Reluctantly giving 5 eggs to balance out my old review since panel is much improved and case is advertised correctly now. Still don’t like the bend-and-break I/O slot covers though.

Did you find this review helpful? Yes No
