QNAP TS-869-PRO-US Diskless System 8-Bay, All-in-One NAS
- 8-Bay
- Usage Ultra high prerformance for large number of users
- Diskless System
- Intel Atom 2.13GHz Dual-core Processor Processor
- 2 x 10/100/1000M
- 2 x USB 3.0 port (Back: 2) 5 x USB 2.0 port (Front: 1; Back: 4)
Specs
Reviews (1)
Any questions? Our AI beta will help you find out quickly.
Try me now
Learn more about the Qnap TS-869-PRO-US
| Brand | QNAP |
|---|---|
| Model | TS-869-PRO-US |
| Type | Desktop NAS |
| Ports | 2 x 1GbE / 2 x eSATA / 2 x USB 3.2 Gen 1 / 5 x USB 2.0 |
|---|
| Port RJ-45 | 2 x 10/100/1000M |
|---|---|
| Port USB | 2 x USB 3.0 port (Back: 2) 5 x USB 2.0 port (Front: 1; Back: 4) |
| Port eSATA | 2 x eSATA |
| HDD Interface | 8 x Hot-swappable and lockable tray |
| Form Factor | 8-Bay |
|---|---|
| Operating System | Embedded Linux |
| Processor | Intel Atom 2.13GHz Dual-core Processor |
| Installed Memory | 1GB RAM (Expandable RAM, up to 3GB) NOTE: 1. The system memory can be increased to 3GB by installing an additional 1GB/2GB SO-DIMM RAM module. 2. For the information of RAM module installation and compatible NAS models, please refer to the QNAP RAM Module Installation Guide |
| Max Memory Capacity | 3GB |
| Included HDD Capacity | Diskless System |
|---|
| Supported Protocols | Networking - TCP/IP (IPv4 & IPv6: Dual Stack) - Dual Gigabit LAN with Jumbo Frame - Multi-IP Settings, Port Trunking/NIC Teaming (Modes: Balance-rr, Active Backup, Balance XOR, Broadcast, IEEE 802.3ad/Link Aggregation, Balance-tlb and Balance-alb) - DHCP Client, DHCP Server - Protocols: CIFS/SMB, AFP (3.1), NFS, FTP, HTTP, HTTPS, Telnet, SSH, iSCSI and SNMP. - Network Service Discovery(UPnP, Bonjour) - Virtual LAN Support - USB Wi-Fi 802.11n Adapter Support (Optional Purchase) Network File Sharing - CIFS/SMB (Plus DFS Support) - AFP - NFS - FTP - WebDAV |
|---|---|
| Management | Disk Management - Single Disk, JBOD, RAID 0 / 1 / 5 /10/ 5+Hot Spare / 6 /10 - Online RAID Capacity Expansion & Online RAID Level Migration - Bad Block Scan & HDD S.M.A.R.T - Global Spare Drive - AES 256-bit Volume-based Encryption - RAID Recovery - Bitmap Support - Supports ISO Mounting (via Web File Manager) Power Management - Wake on LAN - Scheduled Power on/off (Max 15 settings) - Automatic Power on after Power Recovery Access Right Management - Max User Accounts: 4,096 - Max Groups: 512 - Max. Share Folder: 512 - Batch Creating Users - Import/Export Users - User Quota Management - Subfolder Permissions Support |
| Power | 100-240 VAC 50/60Hz |
|---|
| Temperature | 0°C - 40 °C |
|---|---|
| Humidity | 0-95% R.H |
| Features | Centralized Storage and File Sharing Backup Center for Business NAS, iSCSI/ IP-SAN Storage Combo Solution for Server Virtualization iSCSI and Virtualization Deployment Feature-rich All-in-one NAS Applications Private Cloud Storage for Ease of Deployment Exceptional Performance: 221.8 MB/sec Reading, 220.8 MB/sec Writing SuperSpeed USB3.0, SATA 6Gb/s Supported Energy-efficient & Eco-friendly |
|---|---|
| Usage | Ultra high prerformance for large number of users |
| Dimensions | 11.74" x 9.27" x 7.29" |
|---|---|
| Weight | 16.08 lbs. |
| First Listed on Newegg | March 19, 2012 |
|---|
Warranty & Returns
Warranty, Returns, And Additional Information
Warranty
- Limited Warranty period (parts): 2 years
- Limited Warranty period (labor): 2 years
- Read full details
Return Policies
- Return for refund within: 30 days
- Return for replacement within: 30 days
- This item is covered by Newegg.com's 30-Day Return Policy.
- Read full return policy for details.
