QNAP TS-869-PRO-US Diskless System 8-Bay, All-in-One NAS

(1) Write a Review
  • 8-Bay
  • Usage Ultra high prerformance for large number of users
  • Diskless System
  • Intel Atom 2.13GHz Dual-core Processor Processor
  • 2 x 10/100/1000M
  • 2 x USB 3.0 port (Back: 2) 5 x USB 2.0 port (Front: 1; Back: 4)
Specs
Reviews (1)
avatar

Any questions? Our AI beta will help you find out quickly.

Try me now

Learn more about the Qnap TS-869-PRO-US

Model
Brand QNAP
Model TS-869-PRO-US
Type Desktop NAS
Configuration
Ports 2 x 1GbE / 2 x eSATA / 2 x USB 3.2 Gen 1 / 5 x USB 2.0
Interfaces
Port RJ-45 2 x 10/100/1000M
Port USB 2 x USB 3.0 port (Back: 2)
5 x USB 2.0 port (Front: 1; Back: 4)
Port eSATA 2 x eSATA
HDD Interface 8 x Hot-swappable and lockable tray
Configuration
Form Factor 8-Bay
Operating System Embedded Linux
Processor Intel Atom 2.13GHz Dual-core Processor
Installed Memory 1GB RAM (Expandable RAM, up to 3GB)
NOTE:
1. The system memory can be increased to 3GB by installing an additional 1GB/2GB SO-DIMM RAM module.
2. For the information of RAM module installation and compatible NAS models, please refer to the QNAP RAM Module Installation Guide
Max Memory Capacity 3GB
Hard Drive Performance
Included HDD Capacity Diskless System
Convenience
Supported Protocols Networking
- TCP/IP (IPv4 & IPv6: Dual Stack)
- Dual Gigabit LAN with Jumbo Frame
- Multi-IP Settings, Port Trunking/NIC Teaming (Modes: Balance-rr, Active Backup, Balance XOR, Broadcast, IEEE 802.3ad/Link Aggregation, Balance-tlb and Balance-alb)
- DHCP Client, DHCP Server
- Protocols: CIFS/SMB, AFP (3.1), NFS, FTP, HTTP, HTTPS, Telnet, SSH, iSCSI and SNMP.
- Network Service Discovery(UPnP, Bonjour)
- Virtual LAN Support
- USB Wi-Fi 802.11n Adapter Support (Optional Purchase)

Network File Sharing
- CIFS/SMB (Plus DFS Support)
- AFP
- NFS
- FTP
- WebDAV
Management Disk Management
- Single Disk, JBOD, RAID 0 / 1 / 5 /10/ 5+Hot Spare / 6 /10
- Online RAID Capacity Expansion & Online RAID Level Migration
- Bad Block Scan & HDD S.M.A.R.T
- Global Spare Drive
- AES 256-bit Volume-based Encryption
- RAID Recovery
- Bitmap Support
- Supports ISO Mounting (via Web File Manager)

Power Management
- Wake on LAN
- Scheduled Power on/off (Max 15 settings)
- Automatic Power on after Power Recovery

Access Right Management
- Max User Accounts: 4,096
- Max Groups: 512
- Max. Share Folder: 512
- Batch Creating Users
- Import/Export Users
- User Quota Management
- Subfolder Permissions Support
Power
Power 100-240 VAC 50/60Hz
Environmental
Temperature 0°C - 40 °C
Humidity 0-95% R.H
Features
Features Centralized Storage and File Sharing

Backup Center for Business

NAS, iSCSI/ IP-SAN Storage Combo Solution for Server Virtualization

iSCSI and Virtualization Deployment

Feature-rich All-in-one NAS Applications Private Cloud Storage for Ease of Deployment

Exceptional Performance: 221.8 MB/sec Reading, 220.8 MB/sec Writing

SuperSpeed USB3.0, SATA 6Gb/s Supported

Energy-efficient & Eco-friendly
Usage Ultra high prerformance for large number of users
Dimensions & Weight
Dimensions 11.74" x 9.27" x 7.29"
Weight 16.08 lbs.
Additional Information
Date First Available March 19, 2012
