BUFFALO AirStation Pro 802.11n Plenum-Rated Gigabit Concurrent Dual Band PoE Wireless Access Point - WAPS-APG600H

POWER OVER ETHERNET WIRELESS ACCESS POINT

Buffalo's AirStation Pro 802.11n Gigabit Dual Band PoE Wireless Access Point provides high performance 802.11n speeds and coverage, with selectable operation on one of two available bands for greater networking flexibility. Featuring integrated Power over Ethernet (PoE), AirStation Pro 802.11n AP offers easy installation and placement, even on high ceilings, drop ceilings, walls and other locations where power may not be available. It's plenum-rated chassis and multiple mounting options provide greater flexibility in installation locations, enabling users to safely install the unit above ceiling tiles. Additionally, multiple SSID support with VLAN tagging offers easy network segmentation and added security.

SELECTABLE DUAL BAND

Selectable dual band technology allows users to create a Wireless-N network on either the 2.4 GHz frequency or on the less congested 5 GHz frequency. Select operation on the uncongested 5 GHz band for high bandwidth clients or use the more common 2.4 GHz frequency for standard wireless networking needs.

POWER OVER ETHERNET

Integrated Power over Ethernet (PoE) allows the device to be powered without an AC power source for easy installation and placement, even on high ceilings, drop ceilings, walls and other locations where power may not be available. By using a PoE switch, users can install the AP anywhere they can run an Ethernet cable.

MULTI-SSID / VLAN TAGGING

AirStation Pro 802.11n AP allows administrators to create multiple SSIDs with different security passphrases for easy network segmentation and added security. Network administrators can assign each SSID a VLAN tag to specify what network access that SSID gets.

WDS BRIDGING

Wireless Distribution System (WDS) allows users to easily extend coverage of their wireless network by interconnecting multiple access points. Easily bridge a WLAN spanning multiple buildings or expand coverage in a home to hard to reach locations.

PLENUM RATED CHASSIS

AirStation Pro 802.11n AP offers easy installation and placement, even on high ceilings, drop ceilings, walls and other locations where power may not be available. Its plenum-rated chassis and multiple mounting options provide greater flexibility in installation locations, enabling users to safely install the unit above ceiling tiles.

REMOVABLE ANTENNAS

Easily add high gain antennas for longer range, wireless bridging or backhaul solutions. AirStation Pro 802.11n AP uses industry-standard RP-SMA connectors, compatible with readily available third party solutions.

802.1X RADIUS AUTHENTICATION

802.1X RADIUS authentication provides enterprise-grade access restrictions, helping to keep unauthorized users out. By moving authentication to a backend RADIUS server*, only specified and authorized wireless devices are permitted to connect to the wireless network.

*WAPS-AG300H does not have an internal RADIUS server, it supports passing authentication to external RADIUS authentication servers.

LAN Interface
Standard Compliance	IEEE802.3 10Base-T, IEEE802.3u 100Base-TX, IEEE802.3ab 1000Base-T, IEEE802.3x Flow Control, IEEE802.1D Spanning Tree Protocol, IEEE802.1Q VLAN Tagging
Speed and Flow Control	10/100/1000 Mbps
Number of LAN Ports	2 x RJ-45 (1 port PoE, supports 802.3af)
Wireless LAN Interface
Standard Compliance	IEEE802.11n, IEEE802.11a, IEEE802.11g, IEEE802.11b
Frequency Range	Selectable dual band 2.4GHz or 5 GHz Support
Access Mode	Infrastructure Mode
Antenna (Tx x Rx)	2 x 2
Wireless Security	WPA - PSK (AES, TKIP), WPA2-PSK (AES, TKIP), 128/64-bit WEP
USB Interface
Standard Compliance	USB 2.0
Connector Type	A type
Number of Ports	2
Data Transfer Rates	Max 480 Mbps
Other
Dimensions (W x H x D)	5.98 x 7.17 x 1.38 in
Weight	1.34 lbs
Power Consumption	Max 7.2 W (AC), Max 6.72 W (PoE)
Power Supply	External AC 100-240V input, 12V DC Output or IEEE 802.3af PoE
OS Compatibility	Windows® 10, Windows® 8 (32/64-bit), Windows® 7 (32/64-bit), Windows Vista® (32/64-bit), Windows® XP, Mac OS® X
