Specifications: Interfaces/Ports: 1 x RJ-45
Data Transfer Rate: 230 Kbps Serial
Management: SNMP
Protocols:
Telnet
Reverse Telnet
PPP
SSH v2
HTTP
DHCP
ARP
RARP
TCP
UDP
Status Indicators: Link / Power
Input Voltage:
100 V AC to 240 V AC
9 V DC to 30 V DC
Input Current:
400 mA 12 V DC
500 mA 9 V DC to30 V DC
Specifications: What's in the box:
Digi Connect EZ Mini - serial server, 1-port, with accessories
Power supply - 12 V, 2.5 A (76000823)
DIN rail clip (76002095)
Specifications: Interfaces/Ports:
4 x RJ-45
1 x RJ-45
Data Transfer Rate: 230 Kbps Serial
Management:
Telnet
SNMP
Digi Port Authority-Remote
HTTP for easy browser configuration
Status Indicators: Link / Power
Input Voltage:
100 V AC to 240 V AC
9 V DC to 30 V DC
Input Current:
400 mA 12 V DC
500 mA 9 V DC to30 V DC
Specifications: What's in the box:
Digi Connect EZ 2 - serial server, 2-port, with accessories
Power supply - 12 V, 3 A (24000136)
DIN rail clip (76002095)
Specifications: 32 x serial - RS-232 - RJ-45
1 x management - console - RJ-45
1 x network - Ethernet 10Base-T/100Base-TX - RJ-45
Total Expansion Slots: 1
Memory: 64MB SDRAM
Input Voltage: 110 - 220 V AC
Form Factor: Rack-mountable
Dimensions: 17.0" x 8.5" x 1.8"
Weight: 5.8 lbs.
Specifications: Ports: 16 RS-232 serial ports
Throughput: Up to 230 Kbps
Signal Support: TXD, RXD, RTS, CTS, DTR, DSR, DCD
Ethernet:
Physical Layer: 10/100 Base-T
Data Rate: 10/100 Mbps
Mode: Full or Half duplex
USB: 2 ports at .5A max per port
Power Input: 100-240 VAC, 50-60 Hz, 0.4A
Surge Protection: 1 kV burst (EFT) per EN61000-4-4; 2 kV surge transient per
Security: SSL, SSL/TLS, SSHv2, FIPS 197 (serial ports), SNMPv2, PPP
Dimensions: 17.00" x 6.95" x 1.62"
Weight: 5.00 lbs.
