AMD EPYC 4004 Series / AMD EPYC 4005 Series / AMD Ryzen 7000 Series / AMD Ryzen 9000 Series
Number of Processor Support
1
CPU Features
TDP up to 170W
Chipsets
North Bridge
AMD B650
Memory
Memory Slots
4 x DDR5 288-pin
Memory Standard
AMD EPYC 4005 / Ryzen 9000: Up to 5600 MT/s (1DPC), 3600 MT/s (2DPC)
AMD EPYC 4004 / Ryzen 7000: Up to 5200 MT/s (1DPC), 3600 MT/s (2DPC)
Channel Supported
Dual Channel
ECC Supported
Yes
Expansion Slots
PCI Express 5.0 x16
Slot_3: PCIe x16 (Gen5 x16), from CPU, shared with MCIO
PCI Express x4
Slot_1: PCIe x4 (Gen4 x4), from FCH
Other Slots
1 x MCIO 8i (Gen5 x8)
Storage Devices
SATA
4 x SATA 6.0Gb/s
SATA RAID
0/1/10
M.2
1 x M.2 (2242/2280), PCIe Gen5 x4, from CPU
Onboard Video
Onboard Video Chipset
Aspeed AST2600
Onboard LAN
LAN Speed
10/100/1000Mbps
Max LAN Speed
2 x 1Gbps
Rear Panel Ports
Back I/O Ports
2 x USB 3.2 Gen1 ports (Type-A) 1 x VGA port 1 x Serial port 2 x RJ45 ports 1 x MLAN port 1 x ID button with LED
Onboard Ports
Other Connectors
1 x 24-pin ATX main power connector 1 x 8-pin ATX 12V power connector 1 x CPU fan header 5 x System fan headers 1 x M.2 slot 1 x MCIO 8i connector 1 x Front panel header 1 x Backplane board header 1 x PMBUS connector 1 x IPMB connector 1 x TPM header
Dimensions
Form Factor
Micro ATX
Packaging
Package Contents
1 x MC13-LE2 1 x I/O shield 1 x Quick start guide 4 x SATA cables (500mm)
