DDR5 memory delivers blazing 5600MHz speeds for accelerated data processing, enhancing multitasking efficiency and boosting gaming performance. Engineered for productivity and esports dominance.
On-die ECC Technology
PMIC power management chip capable of self-correcting errors generated during data access within memory chips, providing a more stable and reliable operating environment for high-performance computers.
Selected Chips
High-quality, carefully selected chips for enhanced performance; delivering robust and stable performance even under high-intensity operations.
Capacity up to 32GB
Optional capacity of 32GB, doubling the capacity for smooth handling of heavy workloads, improving scalability, and meeting the needs of various user groups.
Plug And Play, Compatible And Reliable
Kingbank has undergone strict compatibility testing with major-brand motherboards and has excellent compatibility, stability and reliability.
Specifications
Product Name
Laptop Memory
Generation
DDR5
Capacity
32GB
Frequency
5600MHz
Voltage
1.1V
Pins
262 pin
Size
76x30x2.2~3.3mm
Learn more about the ASRock Industrial NUC BOX-1340P/D5
General
Brand
ASRock Industrial
Model
NUC BOX-1340P/D5
Part Number
NUC BOX-1340P/D5
Color
Black
CPU Supported
CPU Type
Intel® 13th Gen (Raptor Lake-P) Core™ Processors (i5-1340P, 4P+8E))
Memory Supported
Memory installed
No Memory
Memory slot
2 x 262Pin SO-DIMM
Memory Type Supported
Dual Channel DDR5 4800 MHz
Max Memory Supported
32GB
Dual Channel Memory Supported
Yes
Storage
M.2
1 x M.2 (Key M, 2242/2260/2280) with PCIe Gen4 x4 for SSD *M.2 Key M 2280(Supported by bracket
Graphics
Integrated Graphics
Intel Iris Xe Graphics
Audio
Onboard Audio
Realtek ALC256, High Definition Audio
Communications
LAN
LAN1: Intel® I226LM with 10/100/1000/2500 Mbps LAN2: Intel® I226V with 10/100/1000/2500 Mbps
Max LAN Speed
2.5Gbps
Wireless LAN
1 x Wi-Fi 6E 802.11ax (2.4Gbps)
Bluetooth
BT 5.2
Extension Bays
2.5" Internal Bays
1
Front Panel Ports
Front USB
1 x USB 3.2 Gen2 (Type A) 1 x USB4/ThunderboltTM 4 (Supports DP 2.1 display output) 1 x USB3.2 gen2 (Type-C, Supports DP1.4a display output)
Front Audio Ports
1 (headphone & microphone jack)
Back Panel Ports
HDMI
1 x HDMI 2.0b
DisplayPort
1 x DP1.4a
Rear USB
2 x USB 3.2 Gen2 (Type-A)
RJ45
2 x RJ-45
Power Supply
Input
12V~19V DC-In Jack
Power Supply
19V/90W Power Adapter
Physical SPEC
Dimensions
110.0 x 117.5 x 47.85mm
Material
Plastic with sheet metal
Features
Features
OS Support Windows 10/11 TPM 2.0 onboard IC
Packaging
Packaging
19V/90W Power Adapter 1 x Screw Package 1 x VESA mounting bracket
Additional Information
First Listed on Newegg
May 18, 2023
