This Combo Includes 2 Items
Core Architecture:Intel Xe-HPG (Alchemist)
Manufacturing Process:TSMC 6nm
Xe Cores:24
Shader Units:3072
Ray Tracing Units:24
Memory:8GB GDDR6
Memory Bus:256-bit
Memory Bandwidth:512 GB/s
Core Clock:Base: 1700MHz / Max Boost: 2400MHz
Output Interfaces:3× DisplayPort 2.0 + 1× HDMI 2.0
Power Connectors:Dual 8-pin
TDP / TBP:134W / 185W
Cooling Solution:icicle multi-dimensional cooling system (dual fans + three heat pipes)
Card Dimensions:Approx. 253 x 115 x 42 mm (standard dual-slot)
Recommended PSU:550W or higher
Learn more about the GUNNIR A580 Index 8G
Model| Brand | GUNNIR |
|---|
| Series | A580 Index |
|---|
| Model | A580 Index 8G |
|---|
Interface| Interface | PCI Express x16 4.0 |
|---|
Chipset| Chipset Manufacturer | Intel |
|---|
| GPU Series | Intel Arc A-Series |
|---|
| GPU | Intel A580 |
|---|
| Core Clock | 1700 MHz |
|---|
| Xe-cores | 24 |
|---|
Memory| Effective Memory Clock | 1700 MHz |
|---|
| Memory Size | 8GB |
|---|
| Memory Interface | 256-Bit |
|---|
| Memory Type | GDDR6 |
|---|
3D API| DirectX | DirectX 12 Ultimate |
|---|
| OpenGL | Yes |
|---|
Ports| Multi-Monitor Support | 4 |
|---|
| HDMI | 1 x HDMI 2.0 |
|---|
| DisplayPort | 3 x DisplayPort 2.0 |
|---|
Details| Ray Tracing Support | Yes |
|---|
| Max Resolution | 7680 x 4320 |
|---|
| Cooler | Double Fans |
|---|
| Thermal Design Power | 134W |
|---|
| Recommended PSU Wattage | 650W |
|---|
| Power Connector | 2 x 8-Pin |
|---|
Features| Features | Ray Tracing Support |
|---|
Form Factor & Dimensions| Form Factor | ITX |
|---|
| Max GPU Length | 253 mm |
|---|
| Card Dimensions (L x H) | 253 x 115 x 42 mm |
|---|
| Slot Width | 2 Slots |
|---|
Additional Information| First Listed on Newegg | June 12, 2026 |
|---|
