Question 1

Were there any problems with RAM clearance?

Accepted Answer

I had no problems. I'm using an Asus F2A85-MPRO: http://www.newegg.com/Product/Product.aspx?Item=N82E16813131883 If your DIMM sockets are right beside your cpu, you might have trouble with that... it does rise a bit above the board, though. It was the best thing I could find, since I'm also using a low-profile case. It does take some un/screwing to get the thing mounted, but it works quite well.

Question 2

How tall does this with the fan?

Accepted Answer

If you are worried about this blocking up a PCI slot in a small case this cooler is very slim and no bigger than a stock cooler height wise.

The only worry you'd might have are really high heatsink like on skrill ram. My ram is OC with heatsinks and it goes right up underneath where the heatsink is lipped up.

Question 3

Does anyone know if this will fit an AM3+ mATX board? (BIOSTAR A960D+V2)

Accepted Answer

This might not be helpful at all but I have this on my msi a58-m35 micro atx board and it fits, but it is a very tight fit. They're both micro atx of similar design so you might have luck but I am not sure. I'm sorry I can't give you a definitive answer.

Question 4

Fit in a 2U chassis?

Accepted Answer

The Gelid Sphero 120mm fits in slim HTPC case which is what I used it for. If the 2U server rack chassis case is 4" or taller this will fit.

Question 5

Just trying to figure out if this would fit on my MSI minATX mobo, FM2 socket, short of busting out the ruler. Any thoughts?
Running an A10-5800k Trinity with stock fan/HS

Accepted Answer

I used this for vertical clearance below power supply. Orientation of fan can put it very close to memory. Height of memory could be a factor.

Question 6

What is the weight of this fan/heatsink?

Accepted Answer

The heat sink/fan assembly itself weighs 324 g.  The mounting hardware (brackets, standoffs, screws, plus paste) weigh 32 g.  The entire package and contents (as received) weighs 459 g.  These weights come from a Kitrics digital nutrition scale, and should be +/- 1 g.

Brand	GELID Solutions
Model	CC-Shero-01-A

Color	Black
Type	Fan & Heatsinks
Fan Size	120mm
Bearing Type	Hydro
RPM	750-1600 RPM
Air Flow	52.4 CFM
Noise Level	12-25.4 dBA
Heatsink Material	Aluminum & Copper
Fan Mounting Types to Heatsink	Vertical

Max CPU Cooler Height	59 mm
Weight	0.78 lb.

GELID Solutions CC-Shero-01-A 120mm Hydro CPU Cooler
