Brand | EVGA |
---|---|
Model | 123-LF-E653-KR |
CPU Socket Type | LGA 1156 |
---|---|
CPU Type | Core i3 / Core i5 / Core i7 / Intel Core 1st Gen (LGA 1156) / Pentium |
Chipset | Intel P55 |
---|
Onboard Video Chipset | None |
---|
Number of Memory Slots | 4x240pin |
---|---|
Memory Standard | DDR3 2000MHz+ |
Maximum Memory Supported | 16GB |
Channel Supported | Dual Channel |
PCI Express 2.0 x16 | 2 (x16, x4) |
---|---|
PCI Express x1 | 1 x PCI Express x1 |
PCI Slots | 3 x PCI Slots |
SATA 3Gb/s | 6 x SATA 3Gb/s |
---|---|
SATA RAID | 0/1/0+1/5/JBOD |
Audio Channels | 8 Channels |
---|
Max LAN Speed | 1Gbps |
---|
Back I/O Ports | 1 x Optical S/PDIF Out / 1 x PS/2 / 1 x S/PDIF Coaxial Out / 8 x USB 2.0/1.1 |
---|---|
PS/2 | 1 |
USB 1.1/2.0 | 8 x USB 2.0 |
S/PDIF Out | 1 x Optical, 1 x Coaxial |
Audio Ports | 6 Ports |
Onboard USB | 6 x USB 2.0 |
---|---|
Onboard 1394 | 2 x 1394a |
Form Factor | ATX |
---|---|
Dimensions (W x L) | 12.0" x 9.6" |
Power Pin | 24 Pin |
Date First Available | September 04, 2009 |
---|
