Alphacool Eisblock Aurora Acryl GPX-N RTX 3090/3080 Ti HOF with Backplate (11967)

The Alphacool Eisblock Aurora Acryl GPX-N RTX 3090/3080 Ti HOF with Backplate is a GPU water block for the GALAX and KFA2 GeForce RTX 3080 Ti HOF graphics cards. Alphacool's list below also names a GALAX GeForce RTX 3090. It cools the card with a 5.5 mm nickel-plated copper block, and the black aluminum backplate is in the box.

Properties

• Fits: GALAX and KFA2 GeForce RTX 3080 Ti HOF, GALAX GeForce RTX 3090 as listed below
• Cold plate: Nickel-plated copper, 5.5 mm
• Ports: 4 x G1/4
• Backplate: Aluminum, black, included
• Lighting: Digital RGB LEDs, 5V

Compatibility

Alphacool lists these cards for this block:

• GALAX GeForce RTX 3080 Ti HOF 12GB (38IOM5MD3BHX)
• GALAX GeForce RTX 3090 OC
• KFA2 GeForce RTX 3080 Ti HOF Premium (38IOM5MD3BAK)

The block was built for one PCB layout, so check your own card before ordering. Compare it with the pictures in Alphacool's GPU configurator for graphics cards. You can also look it up here: the Compatibility List for Nvidia graphic cards is a PDF download. Alphacool also makes an active backplate that water-cools the back of the card on this block, the Eisblock Aurora GPX-N Acryl Active Backplate for the HOF cards.

The Aurora Acryl GPX Eisblock

Alphacool presents this graphic card GPU block as one that combines style with performance and extensive digital RGB lighting. It says over 17 years of experience give it the ability to create GPU blocks that represent high quality and fantastic performance, and that this perfectly describes the series. It calls the cooler a complete redevelopment of the previous Alphacool graphics card water coolers. In its words no technical compromises were made, but the entire technical know-how flowed into the development and implementation.

What the loop needs

The block has four G1/4 threads. Two take the compression fittings for your tube size, which are not in the box, and the two you do not use have to stay closed. The lighting connects through a 3-Pin JST plug and runs on 5V.

Technical data cooler

• L x W x H: 295 x 150 x 24.7 mm
• Material cooler: Nickel-plated copper
• Material cooler top: POM clear
• Threads: 4 x G1/4
• Thickness cooling fins: 0.6 mm
• Illumination: Digital RGB LEDs
• Power connector Digital RGB LEDs: 3-Pin JST
• Power Digital RGB LEDs: 5V

Technical data backplate

• L x W x H: 295 x 125.25 x 6 mm
• Material: Aluminum
• Color: Black

Notes

• Alphacool asks that the block be used only with clear transparent water cooling fluids. It warns that the particles and additives in Pastel liquids can clog and permanently damage radiators, pumps, coolers and hoses, and that this can void the manufacturer's warranty.

In the box

• 1x Eisblock Aurora Acryl GPX-N RTX 3090/3080 TI HOF cooler with backplate
