Learn more about the APC AP7750A
ModelBrand | APC |
---|
Model | AP7750A |
---|
DetailsType | Automatic Transfer Switch |
---|
Style | Rackmount |
---|
ROHS | Yes |
---|
InputInput Voltage | 100V, 120V |
---|
Input Frequency | 50/60 Hz |
---|
Maximum Input Current | 15A |
---|
Regulatory Derated Input Current | 12A |
---|
Input Connector(s) | NEMA 5-15P |
---|
Cord Length | 8 ft |
---|
OutputOutput Voltage | 100V, 120V |
---|
Output Watts (VA) | 1440 VA |
---|
Output Connector(s) | (10) NEMA 5-15R |
---|
EnvironmentalOperating Environment | -5 - 45 ºC |
---|
Operating Relative Humidity | 0 - 95% |
---|
Operating Elevation | 0 - 3000 m |
---|
Storage Temperature | -25 - 65 ºC |
---|
Storage Relative Humidity | 0 - 95% |
---|
Storage Elevation | 0 - 15000 m |
---|
FeatureFeatures | APC Automatic Transfer Switch (AP7750A) - NEMA 5-15R - 1.44 kVA - 100 V AC, 120 V AC |
---|
Dimensions & WeightDimensions | 1.73" x 17.01" x 9.29" (H x W x D) |
---|
Weight | 10.36 lbs. |
---|
Additional InformationDate First Available | May 13, 2023 |
---|
