ASRock Rack 1U12XL-C622 RPSU 1U Rackmount Server Barebone LGA 3647 Intel C622 DDR4 2666/2400/2133 R DIMM/LR DIMM

Be the first to review this product...
  • 1U Chassis support 3.5” or 2.5” SATA/SAS HDD/SSD Hot-Swap Bay +2 x 2.5’’ SATA/SAS HDD Hot-Swap Bay with 700W Redundant PSU
  • Intel Xeon processor Scalable family
  • Supports six Channel DDR4 2666/2400/2133 RDIMM/LR DIMM, 16 slots
  • 14 x SATA3 6.0 Gb/s (12 from 3 x mini SAS connector + 2 x SATA connector +2 x M.2 ports from PCH)
  • 2 x USB 3.0 ports
  • ASPEED 2500. Integrated IPMI 2.0 with KVM, vMedia and Dedicated LAN (RTL8211E)
+
+
Specs
Reviews
See all Q & A

Any questions? Ask CelesteSM will help you find out quickly.

Try me now

Learn more about the ASRock Rack 1U12XL-C622 RPSU

General
Brand ASRock Rack
Model 1U12XL-C622 RPSU
Form Factor 1U Rackmount
CPU Supported
CPU Type Intel Xeon
CPU Socket LGA 3647
Max Processors 2
Chipset
North Bridge Intel C622
Memory Supported
Memory Slots 16 x 288Pin
Installed Memory Size No Memory Installed
Max Memory Supported 1TB
Memory Type Supported DDR4 2666/2400/2133 R DIMM/LR DIMM
Storage Supported
Serial ATA 14 x SATA3 6.0 Gb/s (12 from 3 x mini SAS connector + 2 x SATA connector +2 x M.2 ports from PCH)
Graphics
Video Memory ASPEED AST2500
Expansion Slots
PCI Express 2x PCI Express x8
Communications
First LAN 1 x Realtek RTL8211E for dedicated management LAN
Panel Ports
Rear USB 2 x USB 3.2 Gen1
RJ45 1 x RJ45 Dedicated IPMI LAN port
LAN Ports with LED (ACT/LINK LED and SPEED LED), dedicate for IPMI
Other Ports Internal Connector
COM Header: 1
Auxiliary Panel Header: 1 (include chassis intrusion, location button & LED, front LAN LED)
TPM Header: 1
IPMB Header: 1
VGA Header: 1
Fan Header: 6 x System Fans (6-pin)
ATX Power: 1x (24-pin) + 2x (8-pin)
NMI Button: 1
Front Panel: 1
Dimensions & Weight
Dimensions 1.70" x 33.90" x 17.20"
Additional Information
First Listed on Newegg November 24, 2021

Warranty & Returns

Warranty, Returns, And Additional Information

Warranty

  • Limited Warranty period (parts): 3 years
  • Limited Warranty period (labor): 3 years
  • Read full details

Return Policies

    We want to ensure your holiday shopping this year is hassle-free. That’s why we’re automatically extending our return policies on almost every product! For purchases placed between November 1st, 2026 and December 31, 2026 you will have until January 31, 2027 to return your product.

  • Return for refund until: January 31, 2027
  • Return for replacement until: January 31, 2027
  • This item is covered by Newegg.com's Extended Holiday Return Policy.
  • Read full return policy for details.

Manufacturer Contact Info

LOADING...

The ASRock Rack 1U12XL-C622 RPSU is a 1U server barebone for data centers and enterprise IT teams building a compact, dual-socket Intel Xeon Scalable system with hot-swap storage, up to 1TB of DDR4 memory, and a 700W redundant power supply.

Recommended For

  • Rack operators building dense shared-storage or backup servers who need 12 hot-swap 3.5-inch drive bays plus two 2.5-inch bays in a 1U chassis.
  • Server administrators who need out-of-band maintenance—such as remote KVM access and virtual media—for systems deployed in a rack or data center.
  • IT teams that prioritize service continuity and want redundant power supplies in a rackmount storage or server build.
  • System integrators building around supported Intel Xeon Scalable processors and registered or load-reduced DDR4 memory, with room to configure a high-capacity server platform.

Spec Summary

AttributeValue
Best ForServer builds needing a 1U rackmount platform for up to two Intel Xeon processors and up to 1TB of supported memory
Processor And PlatformIntel Xeon processors on an LGA 3647 socket with an Intel C622 chipset
Memory Configuration16 x 288-pin slots support DDR4 2666/2400/2133 RDIMM or LR DIMM, with up to 1TB supported; no memory is installed
Storage And Drive Support14 SATA3 6.0 Gb/s connections: 12 through three mini-SAS connectors, two SATA connectors, and two M.2 ports from the PCH; 2.5-inch hard drives are listed as supported
ExpansionTwo PCI Express x8 slots
Management And NetworkingDedicated Realtek RTL8211E management LAN with RJ45 and ACT/LINK and speed LEDs
USB ConnectivityTwo rear USB 3.x Gen 1 ports
Internal Headers And ControlsIncludes COM, auxiliary panel, TPM, IPMB, VGA, and front-panel headers; six 6-pin system-fan headers and an NMI button
Chassis, Power And CoolingIntegrated 1U rackmount chassis with air cooling; 24-pin ATX and two 8-pin power connectors
Dimensions1.70 x 33.90 x 17.20 inches
Model IdentifiersASRock Rack 1U12XL-C622 RPSU
