Learn more about the ASRock Rack 4U8G-TURIN2
GeneralBrand | ASRock Rack |
---|
Model | 4U8G-TURIN2 |
---|
Form Factor | 4U Rackmount |
---|
Workload | General Purpose Server |
---|
CPU SupportedCPU Type | AMD EPYC 9005 & 9004 Series |
---|
CPU Socket | Socket SP5 |
---|
Installed CPU | No CPU Installed |
---|
Max Processors | 2 |
---|
CPU Features | Thermal Design Power Up to 500W |
---|
Memory SupportedMemory Slots | 24 x 240Pin |
---|
Installed Memory Size | No Memory Installed |
---|
Max Memory Supported | 12TB |
---|
Memory Type Supported | DDR5 6400 |
---|
Registered | Yes |
---|
Storage SupportedInstalled HDD | No Storage Installed |
---|
M.2 | 1 M-key (PCIe3.0 x4 or SATA 6Gb/s), supports 22110/2280 form factor [CPU0] 1 M-key (PCIe3.0 x4 or SATA 6Gb/s), supports 22110/2280 form factor [CPU1] |
---|
GraphicsGPU/VPU | Aspeed AST2600 |
---|
Expansion SlotsPCI Express | Rear: 8 FHFL dual-slot PCIe5.0 x16 (CPU direct link) Front: 1 FHHL PCIe5.0 x8 |
---|
CommunicationsFirst LAN | Intel I350 |
---|
Max. LAN Speed | 10/100/1000Mbps |
---|
Expansion BaysHot-Swap Bays | 4 Hot-swap 2.5" NVMe (PCIe5.0 x4) drive bays 20 Hot-swap 2.5" SATA/SAS* drive bays |
---|
Panel PortsButtons | Power button w/ LED, Reset button, NMI button, UID button |
---|
LEDs | System fault LED, HDD activity LED |
---|
Front USB | 4 x USB 3.2 Gen 1 Type-A |
---|
VGA | 2 |
---|
RJ45 | 2 |
---|
Power SupplyMax. Power | 3+1 CRPS 1000W @ 100-127Vac input / 2700W @ 200-240Vac input |
---|
SystemBIOS Features | AMI UEFI BIOS; 256 Mb (32MB) SPI Flash ROM ASRock Rack Instant Flash, ACPI 6.4 and about compliance wake up events, SMBIOS 3.5.0 and above, Plug and Play(PnP) |
---|
CoolingFans | 5 Middle Hot-swap 80x80 mm fans |
---|
EnvironmentTemperature | Operation temperature: 10°C ~ 35°C / Non operation temperature: -40°C ~ 70°C |
---|
Humidity | Non operation humidity: 20% ~ 90% ( Non condensing) |
---|
Dimensions & WeightDimensions | 6.9" x 30.9" x 17.2" |
---|
Additional InformationDate First Available | July 01, 2025 |
---|
