Question 1

How loud is this computer? I am hoping it is pretty quiet. Thank you.

Accepted Answer

everything is relative to the individual. i think it is very quiet. you can hardly hear the fan at all. the hard drive makes a little noise in the background, and it is running gently pretty much all the time.

it is blazingly fast, but i am having a little intermittent trouble with it not coming out of sleep mode correctly. sometimes it goes to a black screen and says it cannot find a boot device. you have to turn it off and back on.  i don't think it is the hard drive. i am thinking either a cabling issue or perhaps the BIOS or perhaps the computer is just too fast and cannot find the hard drive as soon as the OS wants to see it.

i have been meaning to contact ASUS about this but haven't gotten around to it yet. so far it has just been a minor annoyance.

Question 2

Does this computer have wireless and if so is it dual band?

Accepted Answer

No it doesn't come with wireless.  It has an Ethernet connector, so you can connect it by cable to a wireless router if the router is located near your PC.  But if your wireless router is in another room, as mine is, you will need a USB wireless adaptor to connect to your home network.

Question 3

If I add a powerful graphics card and an SSD drive, will the power supply be able to handle it?

Accepted Answer

NO! Not that the power supply is the problem because there is no room to fit a good graphics card.  I don't know too much about graphics cards but most good cards need two slots/ two levels but this computer only allows one unless you cut through metal.  Also the motherboard layout is bad because the RAM cards block the graphics card so you only have about 5-6 inches and most good cards are like 10-12 inches.

Question 4

Does the computer have a FireWire 400 (6 pin), or a eSATA port, if so how many?
Thanks
Dave

Accepted Answer

Neither and no internal connection on Mobo for either.

You would need to add a Card if USB 3.0 is not available or fast enough for you.

Available expansion slots are:
1 x PCIe 2.0 x16
1 x PCIe 2.0 x16 (x1 mode)
2 x PCIe 2.0 x1

Mobo is ASUS p8h61-m pro/cm6630/dp

Question 5

Does this computer ship with a Windows disk for recovery/rebuild ?

If not, this is a deal killer.

Accepted Answer

There was no separate disk with my Asus but there is a D drive on the hard drive for recovery. You can burn your own disk from this drive if you prefer by hitting F9 when rebooting and making that selection. It says this area contains the OS, drivers and utilities.

Question 6

How many PCI express slots are in this computer?   what size.. 16 bit, 32 bit ...  ??

Accepted Answer

4 slots 64 bit

Question 7

What model motherboard?  What expansion slots?  The Newegg site says it has a PCI slot, but if this computer has an H61M motherboard, then it does not have PCI.  Which is it?

Accepted Answer

Installed an ASUS wi-fi adapter PCI in my unit, so the motherboard has 2 PCI slots.

Question 8

What kind of card slots does this PC have?

Accepted Answer

www .newegg .com/ Product/ Product.aspx? Item=83-220-319
Remove all the spaces as this reply does not like HTML links.

Question 9

Does the motherboard have RAID capability?  How many SATA connectors are there on the motherboard?

Accepted Answer

No RAID 6 SATA connectors, two already in use (HDD+DVD). Video will support 2 monitors, but only VGA+HDMI, no DVI. I added a cheap video card for 2X DVI;

FWIW, this is my first machine in a LONG while that I didn't build up myself, and I've been quite happy with it so far. But it was at $650 when I bought it. Still seems like a good deal at $779, though.

Question 10

Is the RAM expandable to 32GB?

Accepted Answer

I have two 8gb ram, and there are only two slots. So if you want to expand to 32gb you have to buy two 16gb RAM.

Brand	ASUS
Model	CM6730-US005O

Usage	Consumer
Processor	Intel Core i7-3770 3.4GHz
Processor Main Features	64 bit Quad-Core Processor
Cache Per Processor	8MB L3 Cache
Memory	16GB DDR3 1600MHz
Storage	2TB 7200RPM
Optical Drive	24x DVD-RW
Graphics	Intel HD Graphics 4000
Ethernet	Gigabit Ethernet
Power Supply	300W
Operating System	Windows 7 Home Premium
Software Included	Anti-Virus Trial Office 2010 Starter or Office trial Microsoft Pack Adobe Reader SKYPE (Windows 8) Freshpaint (Windows 8) Windows 8 Games ASUS AI-SUITE II ASUS AI Manager ASUS My Logo2 ASUS Update ASUS Q-fan ASUS@Vibe ASUS AI Charger ASUS WebStorage ASUS Music Maker

CPU Type	Intel Core i7
CPU Name	Intel Core i7-3770
L3 Cache Per CPU	8 MB
CPU Socket Type	LGA 1155
CPU Main Features	64 bit Quad-Core Processor Max Turbo Frequency 3.9 GHz

GPU/VGA Type	Intel HD Graphics 4000
Graphics Interface	Integrated video

Memory Capacity	16GB DDR3
Memory Speed	DDR3 1600

ASUS Desktop PC CM6730-US005O Intel Core i7-3770 16GB DDR3 2TB HDD Intel HD Graphics 4000 Windows 7 Home Premium

Learn more about the ASUS CM6730-US005O

Customer Reviews of the ASUS CM6730-US005O

Warranty & Returns

Warranty, Returns, And Additional Information

Warranty

Return Policies

Manufacturer Contact Info

Front USB	2 x USB 2.0
Front Audio Ports	2
Card Reader	6-in-1 Card Reader

PS/2	1
Video Ports	1 VGA, 1 HDMI
Rear USB	2 x USB 3.0 4 x USB 2.0
RJ45	1 port
Rear Audio Ports	8 channel Audio I/O
S/P DIF	1 port

Storage
HDD	2TB
HDD RPM	7200rpm
Storage Spec	3.5"

Dimensions & Weight
Dimensions (H x W x D)	15.8" x 14.2" x 6.8"
Weight	17.4 lbs.
