Can I get a list of what exactly comes included in this package? From what I can see I will still need to purchase memory and a hard drive. Looks like it comes with the motherboard, processor, dvd drive, case, and wiring. Is this correct or am I missing something?

You are close but the processor is not included. However, there is a heat sink included. You add a compatible Intel processor, memory and disk drive(s) and you are good to go. I have about a dozen Asus 1u servers and they have been the most reliables set I ever had. I highly recommend this unit if you are ok installing the components yourself.

WHAT SIZE SOLID STATE DRIVES CAN I PUT INTO THIS SYSTEM AND WHAT IS THE MAXIMUM?

I am running mine with 2 2.5 inch SSD drives. Plenty of space and wiring was easy. You can also add more on the PCI bus. 1.8 inch drives should be fine too. I have many ASUS servers and they have been the most stable brand I have used to date.

Out of stock

This item is currently out of stock and it may or may not be restocked.

Out of Stock

Add to wish list

Sold by Newegg

Shipped by Newegg

More Resources

ASUS RS100-E7/PI2 User Manual

Main image of ASUS RS100-E7/PI2 1U Rackmount Server Barebone LGA 1155 Intel C204 DDR3 1600/1333/1066

Alt view image 2 of 7 - ASUS RS100-E7/PI2 1U Rackmount Server Barebone LGA 1155 Intel C204 DDR3 1600/1333/1066

Alt view image 3 of 7 - ASUS RS100-E7/PI2 1U Rackmount Server Barebone LGA 1155 Intel C204 DDR3 1600/1333/1066

Alt view image 4 of 7 - ASUS RS100-E7/PI2 1U Rackmount Server Barebone LGA 1155 Intel C204 DDR3 1600/1333/1066

Alt view image 5 of 7 - ASUS RS100-E7/PI2 1U Rackmount Server Barebone LGA 1155 Intel C204 DDR3 1600/1333/1066

Alt view image 6 of 7 - ASUS RS100-E7/PI2 1U Rackmount Server Barebone LGA 1155 Intel C204 DDR3 1600/1333/1066

Alt view image 7 of 7 - ASUS RS100-E7/PI2 1U Rackmount Server Barebone LGA 1155 Intel C204 DDR3 1600/1333/1066

Shop All ASUS Products

ASUS RS100-E7/PI2 1U Rackmount Server Barebone LGA 1155 Intel C204 DDR3 1600/1333/1066

(15) Write a Review

LGA 1155
Intel Xeon E3-1200 & v2, Core i3-2100 Series
4 x 240Pin Memory Slots
220W 80PLUS Single Power Supply

Overview

Specs

Reviews (15)

Any questions? Our AI beta will help you find out quickly.

Try me now

General
Brand	ASUS
Model	RS100-E7/PI2
Form Factor	1U Rackmount

CPU Supported
CPU Type	Intel Xeon E3-1200 & v2, Core i3-2100 Series
CPU Socket	LGA 1155

Chipset
North Bridge	Intel C204

Memory Supported
Memory Slots	4 x 240Pin
Max Memory Supported	32GB
Memory Type Supported	DDR3 1600/1333/1066
ECC Supported	Yes

Storage Supported
Serial ATA	2 x SATA 600
SATA RAID	Intel Rapid Storage Technology(RST) (For Windows Only) (Support Software RAID 0, 1 ) LSI MegaRAID (For Linux/Windows) (Support Software RAID 0, 1 )

Graphics
GPU/VPU	Aspeed AST2050
Video Memory	16MB

Expansion Slots
PCI Express	1 x PCI-E x16 (Gen3/Gen2 x16 link) (Full-Height/HL) Gen3 link can only be supported with Intel Xeon E3-1200 v2 Processor

Communications
First LAN	Intel 82574L
Second LAN	Intel 82574L
Max. LAN Speed	Dual 1 Gigabit

Expansion Bays
3.5" Bays	2 x Internal 3.5"
Slim Bays	1

Panel Ports
Front USB	2
COM	1
PS/2	2
VGA	1
Rear USB	2
RJ45	3 x RJ-45 (1 for Mgmt LAN)

Power Supply
Max. Power	220W 80PLUS Single Power Supply

Features
Features	Processor: Intel Xeon E3-1200 Processor Family Intel Xeon E3-1200 v2 Processor Family Intel Core i3-2100 Processor Family Intel Pentium G8x0/G6x0 Intel Celeron G5x0/G4x0 Software: ASWM Enterprise 2.0 Note: DDR3 1600 can only be supported with Intel Xeon E3-1200 v2 Processor

Dimensions & Weight
Dimensions	380mm x 430mm x 43.4mm
Weight	6.5Kg

Additional Information
First Listed on Newegg	May 23, 2011

Warranty & Returns

Warranty, Returns, And Additional Information

Warranty

Limited Warranty period (parts): 3 years
Limited Warranty period (labor): 3 years
Read full details

Return Policies

Return for refund within: 30 days

Return for replacement within: 30 days

This item is covered by Newegg.com's 30-Day Return Policy. Read full return policy for details.

Manufacturer Contact Info

Manufacturer Product Page
Manufacturer Website
Support Phone: 1-510-739-3777
Support Website
