Asus RS300-E9-PS4 Barebone System - 1U Rack-mountable - Intel C232 Chipset - Socket H4 LGA-1151 - 1 x Processor Support
See more "barebones server"
In stock.
Ships from United States.
Most customers receive within 2-6 days.
- LGA 1151
- Intel Xeon processor E3-1200 v5 product family
- Single 400W 80 PLUS Gold Power Supply Rating: 100-240V AC, 6-3A 60-50Hz, Class 1
Specs
Reviews
Learn more about the ASUS RS300-E9-PS4
| Brand | ASUS |
|---|---|
| Model | RS300-E9-PS4 |
| CPU Type | Intel Xeon processor E3-1200 v5 product family |
|---|---|
| CPU Socket | LGA 1151 |
| North Bridge | Intel C232 |
|---|
| Max Memory Supported | 64GB |
|---|---|
| Memory Type Supported | DDR4 2133 UDIMM non ECC and with ECC |
| Channel Supported | Dual Channel |
| Serial ATA | Intel C232 6 x SATA3 6Gb / s ports 2 x M.2 connector (2280 / 2260 / 2242) Intel Rapid Storage Technology Enterprise(RSTe) (For Windows Only) (Support Software RAID 0, 1, 5, 10 ) |
|---|---|
| SATA RAID | RAID 0/1/5/10 |
| SAS | ASUS PIKE II 3008-8i 8-port SAS 12G RAID card (Optional) ASUS PIKE II 3108-8i 8-port SAS 12G HW RAID card (Optional) |
| PCI Express | Total PCI / PCI-X / PCI-E / PIKE Slots: 2 1 x PCI-E x16 (x8 Gen3 Link) 1 x PCI-E x8 (x8 Gen3 Link) |
|---|
| First LAN | Intel I210-AT |
|---|
| Slim Bays | 1 x Slim-type Optical Drive Bay |
|---|---|
| Hot-Swap Bays | 4 x 3.5” Hot-Swap HDD Bays |
| PS/2 | 1 x PS/2 KB / MS port |
|---|---|
| VGA | 1 |
| Rear USB | 2 x USB 3.0 ports 2 x USB 2.0 ports |
| RJ45 | 4 |
| Other Ports | Total PCI / PCI-X / PCI-E / PIKE Slots: 2 1 x PCI-E x16 (x8 Gen3 Link) 1 x PCI-E x8 (x8 Gen3 Link) |
| Max. Power | Single 400W 80 PLUS Gold Power Supply Rating: 100-240V AC, 6-3A 60-50Hz, Class 1 |
|---|
| Features | Platinum power efficiency with up to 94.4% Optimized thermal design for heat sink and heat pipe Advanced storage support with dual M.2 Quad Intel I210 Server Class GbE delivering high networking bandwidth |
|---|
| Form Factor | 1U Rackmount |
|---|
| Dimensions | 1.73" x 24.21" x 17.48" |
|---|---|
| Weight | 19.80 lbs. |
| Date First Available | October 08, 2020 |
|---|
Warranty & Returns
Warranty, Returns, And Additional Information
Warranty
- Limited Warranty period (parts): 3 years
- Limited Warranty period (labor): 3 years
- Read full details
Return Policies
- Return for refund within: 30 days
- Return for replacement within: 30 days
- This item is covered by Computer Headquarters Return Policy
Manufacturer Contact Info
- Manufacturer Product Page
- Manufacturer Website
- Support Phone: 1-510-739-3777
- Support Website
- View other products from ASUS
LOADING...
Pros: Nothing
Cons: There is no warranty on these servers. Manufactures warranty is worthless. The warranty is "you might get a server sometime". My server did not boot and they can't find a replacement of their flagship model. What a headache. Waiting three weeks and still no response but, we are working to find you a replacement.
