does this include the heatsink for the cpu? also does it come with the rack rails?

The product does not include a CPU and does not specify whether it includes a heatsink or rack rails.

does it comes with a processor installed?

No, this server does not come with a processor installed.

does it comes with a processor installed?

No, it does not come with a processor installed.

Out of stock

$1,488^.99

Price alert

Add to wish list(Found on 2 wish lists)

Sold by Newegg

Shipped by Newegg

Main image of ASUS RS500A-E11-WOCPU006Z 1U Rackmount Server Barebone Socket SP3 DDR4 3200 RDIMM / LRDIMM / LRDIMM 3DS

Alt view image 2 of 3 - ASUS RS500A-E11-WOCPU006Z 1U Rackmount Server Barebone Socket SP3 DDR4 3200 RDIMM / LRDIMM / LRDIMM 3DS

Alt view image 3 of 3 - ASUS RS500A-E11-WOCPU006Z 1U Rackmount Server Barebone Socket SP3 DDR4 3200 RDIMM / LRDIMM / LRDIMM 3DS

Shop All ASUS Products

ASUS RS500A-E11-WOCPU006Z 1U Rackmount Server Barebone Socket SP3 DDR4 3200 RDIMM / LRDIMM / LRDIMM 3DS

(2) Write a Review

Socket SP3
Supports AMD EPYC 7002 / 7003 Series
16 x 288Pin Memory Slots
800W Redundant, 80 Plus

This item is covered under the Manufacturer Only Return Policy.

Overview

Specs

Reviews (2)

Any questions? Our AI beta will help you find out quickly.

Try me now

General
Brand	ASUS
Model	RS500A-E11-WOCPU006Z
Form Factor	1U Rackmount
Workload	General Purpose Server

CPU Supported
CPU Type	Supports AMD EPYC 7002 / 7003 Series
CPU Socket	Socket SP3
Installed CPU	No CPU Installed
Max Processors	1
CPU Features	Supports 3rd Gen AMD EPYC processors with AMD 3D V-Cache technology

Memory Supported
Memory Slots	16 x 288Pin
Installed Memory Size	No Memory Installed
Max Memory Supported	4TB
Memory Type Supported	DDR4 3200 RDIMM / LRDIMM / LRDIMM 3DS
Channel Supported	8 Channel

Storage Supported
Installed HDD	No Storage Installed
Serial ATA	12 x SATA/SAS/NVMe
M.2	2

Expansion Slots
PCI Express	1 x PCIe x16 slot (Gen4 x16 link,FH,HL) 1 x PCIe x16 slot (Gen4 x16 link,LP,HL) 1 x PCIe x16 slot (Gen4 x8 link,LP,HL) 1 x OCP3.0 slot (Gen4 x16 link)

Communications
First LAN	Intel I350-AM2
Max. LAN Speed	1 Gigabit

Expansion Bays
2.5" Bays	12 x 2.5" Hot-swap Storage Bays

Panel Ports
COM	1
VGA	1 x VGA (Rear)
Rear USB	2 x USB 3.2 Gen1
RJ45	2 x 1GbE LAN ports (RJ45)
Other Ports	1 x Management port (RJ45)

Power Supply
Max. Power	800W Redundant, 80 Plus

Environment
Temperature	Operating temperature: 10°C - 35°C Non operating temperature: -40°C - 70°C
Humidity	Non operating humidity: 20% - 90% (Non condensing)

Features
Features	Powered by AMD EPYC 7003 processor with 64 cores, 128 threads and support for a maximum TDP of up to 280 watts per socket GPU-optimized design allows one dual-slot or two single-slot GPUs for AI workloads Up to 12 all-flash NVMe drives on front panel is designed for high storage throughput performance Up to three PCIe 4.0 slots to enable higher bandwidth and improved data-transfer rates Flexible onboard LAN-module design to enable four 1 Gb LAN or two 10 Gb LAN options Flexible cooling solution achieves lower power-usage effectiveness (PUE) and optimized TCO for data centers Onboard ASUS ASMB10-iKVM for out-of-band management with ASPEED AST2600 controller Integrated PFR FPGA as the platform Root-of-Trust solution for firmware resiliency High power efficiency with redundant 1600W 80 Plus Titanium and Platinum power supplies

Dimensions & Weight
Dimensions	33.17" x 17.68" x 1.73"
Weight	37.48 lbs.

Additional Information
First Listed on Newegg	September 15, 2021

Warranty & Returns

Warranty, Returns, And Additional Information

Warranty

Limited Warranty period (parts): 3 years
Limited Warranty period (labor): 3 years
Read full details

Return Policies

Return for refund within - Contact Manufacture for Assistance

Return for replacement - Contact Manufacture for Assistance

This item is covered by Newegg.com's Manufacturer Only Return Policy. Read full return policy for details.

Manufacturer Contact Info

Manufacturer Product Page
Manufacturer Website
Support Phone: 1-510-739-3777
Support Website
