ASUS 2U RS720-E10-RS12E 2U server Barebone with dual 3rd Gen Intel® Xeon® CPUs, 32 DIMMs, 4 dual-slot GPUs, 8 NVMe, 9 PCIe 4.0, OCP 3.0 and M.2
- Powered by dual-socket 3rd Gen Intel Scalable processors, 32 DIMMs and support for a maximum TDP of up to 270 W per socket
- Optional GPU-optimized design allows four dual-slot GPUs for AI workloads
- Up to eight all-flash NVMe and four SATA/SAS drives on front panel, plus 2 optional NVMe in rear panel to enable extensive storage and high-throughput performance
- Up to nine PCIe® 4.0 slots to enable higher bandwidth and improved data-transfer rates
- Flexible onboard LAN-module design to enable four 1 Gb LAN or two 10 Gb LAN options
- Flexible air- and liquid-cooling solution to achieve lower power-usage effectiveness (PUE) and optimized TCO for data centers
- Onboard ASUS ASMB10-iKVM for out-of-band management with ASPEED AST2600 controller
- Integrated PFR FPGA as the platform Root-of-Trust solution for firmware resiliency
- High power efficiency with redundant 2400 W 80 Plus® Platinum power supplies
Specs
Reviews
Any questions? Our AI beta will help you find out quickly.
Try me now
Learn more about the ASUS RS720-E10-RS12E-16K10L
| Brand | ASUS |
|---|---|
| Model | RS720-E10-RS12E-16K10L |
| Form Factor | 2U Rackmount |
| CPU Type | 3rd Gen Intel Xeon Scalable Processors Family (270W) |
|---|---|
| CPU Socket | 2 x Socket P+ (LGA 4189) |
| Installed CPU | No CPU Installed |
| Max Processors | 2 |
| CPU Features | UPI (11.2 GT/s) |
| North Bridge | Intel C621A |
|---|
| Memory Slots | 32 x 288Pin |
|---|---|
| Installed Memory Size | No Memory Installed |
| Max Memory Supported | Maximum up to 6TB per socket |
| Memory Type Supported | DDR4 3200/2933 RDIMM DDR4 3200/2933 LRDIMM DDR4 3200/2933 LR-DIMM 3DS 3200/2933 RDIMM 3DS |
| Installed HDD | No Storage Installed |
|---|---|
| Serial ATA | 8 x NVMe/SATA/SAS* + 4 x SATA/SAS* *SAS support only from SAS HBA/RAID card |
| M.2 | 2 x M.2 connector (NGFF 2280/2260. PCIe Gen4x4 link) |
| PCI Express | Up to 9 x Expansion slots 2 x PCIe Gen4 x8 or 1 x PCIe Gen4 x16, FHFL (CPU1 x1) 1 x PCIe Gen4 x8, FHFL (CPU1 x1) 1 x PCIe Gen4 x16, FHFL or OCP 3.0 NIC socket (CPU1 x1) 4 x PCIe Gen4 x8 or 2 x PCIe Gen4 x16, FHFL (CPU2 x2) 1 x PCIe Gen4 x8 or x16, LP (if PCIe M.2 in use, it will operate at x8 link) (CPU2 x1) *Installing GPU cards will occupied expansion slots. |
|---|
| First LAN | Intel I710-AT2 |
|---|---|
| Max. LAN Speed | 10 Gigabit |
| 2.5" Bays | 2 |
|---|---|
| 3.5" Bays | 12 |
| VGA | 1 x VGA (Rear) |
|---|---|
| Rear USB | 2 x USB 3.2 Gen1 |
| RJ45 | 2 x RJ-45 10GbE LAN ports |
| Other Ports | 1 x RJ-45 Mgmt LAN port |
| Max. Power | 1600W Redundant, 80 Plus |
|---|
| Temperature | Operation temperature: 10°C ~ 35°C Non operation temperature: -40°C ~ 60°C |
|---|---|
| Humidity | Non operation humidity: 20% ~ 90% ( Non condensing) |
| Dimensions | 33.07" x 17.68" x 3.46" |
|---|---|
| Weight | 40.11 lbs. |
| First Listed on Newegg | November 08, 2023 |
|---|
