| Standards | IEEE 802.11b/g |
|---|
| Wireless Data Rates | Up to 125Mbps |
|---|
| Security | Hardware 64/128-bit WEP engine; WEP weak-key avoidance, TKIP, hardware AES engine supporting CCM and OCB, 802.1x, SSN WPA/WPA2 |
|---|
| Interface | USB 2.0 |
|---|
| Frequency Band | 2.412 GHz - 2.484 GHz |
|---|
| Channels | 802.11b: 11 for North America, 13 for Japan, 13 for Europe (ETSI) 802.11g: 13 for North America, 13 for Europe (ETSI), 13 for Japan |
|---|
| Modulation | Modulation Techniques: BPSK, QPSK, CCK, 16QAM, 64QAM Modulation Technology: OFDM, DSSS |
|---|
| Transmitted Power | 802.11g: 13.5 dBm(for All Location) Typical output power (± 1.5 dBm over operating temperature)
802.11b: 17.5 dBm (for US);14 dBm(for Other Location) Typical output power (± 1.5 dBm over operating temperature) |
|---|
| Antenna | Planar Inverted-F Antenna (PIFA) |
|---|
| System Requirements | Microsoft WHQL certified for Windows XP |
|---|
