Brand | ASUS |
---|---|
Model | WL-500GP V2 |
Standards | IEEE802.11b/g/d, IEEE802.3/3u, 802.1X (security authentication), 802.11i - Ready (security WPA2), 802.11e - Ready (wireless QoS), IPv4 |
---|---|
Device Management | Bandwidth: Allow multiple network activities (FTP, Game, P2P…) to work smoothly at the same time Network: Internet connection type: Automatic IP, Static IP, PPPoE (MPPE supported), PPTP, Bigpond Service Support UPnP IGD DHCP Server: Supports up to 253 IP addresses Changeable DHCP lease time, IP pool, domain name Support DNS Proxy Support NTP Client Support DDNS Smart Wizard browser-based administration: Managed from LAN and Internet Password Setting System Event Log Upgrade via Web Interface Save/Restore Configuration File |
Security | Open System, Shared Key, 64/128-bit WEP, WPA-PSK, WPA2-PSK, WPA-Auto-Personal, WPA-Enterprise, WPA2-Enterprise, Radius with 802.1x |
WPA | WPA2 |
WAN Ports | 1 x 10/100M |
LAN Ports | 1 x 10/100M |
Buttons | EZ Setup button: Push for 5 seconds to setup SSID and WEP or WPA configuration with WSC compliant automatically. Reset Button: Push for above 5 seconds to restore factory settings. |
Wireless Data Rates | Up to 54Mbps |
Operating Range | Indoor 130 ft (40 m), outdoor (LOS, Light-Of-Sight) 2000 ft (600 m) at 11Mbps* Indoor 80 ft (25 m), outdoor (LOS, Light-Of-Sight) 500 ft (150 m) at 54Mbps* *The range may vary by different environment |
Frequency Band | 2.4 GHz - 2.5 GHz |
Transmitted Power | 802.11g: 15~19 dBm* 802.11b: 17~21 dBm* *At normal temp range |
Receiver Sensitivity | -72~-74dBm @54Mbps* -85~-87dBm @11Mbps* -94~-96dBm @ 1Mbps* *At normal temp range |
Interface | 2 x USB 2.0 |
Power Adapter | AC Input: 100V~240V(50~60HZ), DC Output: +5V with max. 2.5A current |
Features | Certification Compliant: CE / FCC / Telec / SRRC / DGT / MIC / C-tick / IDA / SIRIM / IC Wireless Bridge Mode: AP Only WDS Hybrid MAC Access Control: Control the access by the MAC address RADIUS Setting: Required in Radius with 802.1x, WPA, WPA2 mode SSID Isolation: Support SSID hiding WMM: WMM (Wi-Fi Multimedia) support Wireless Separation: Prevent wireless clients from communicating with each other BroadRange: WL-500gP V2 adopts BroadRange technology to broaden coverage to 300% of 11g. The Extend Range WL-500gP V2 can connect to any wireless LAN cards with longer distance. 3 minutes complete FTP setting via ASUS AiDisk |
---|
Package Contents | WL-500g Premium V2 RJ45 Cable Power Adapter Quick Start Guide Resource Disk |
---|
Date First Available | May 05, 2008 |
---|
