THE CS1732B IS A TWO PORT KVMP SWITCH COMBINED WITH A TWO-PORT USB 2.0 HUB. AS A
Learn more about the ATEN CS1732B
Model
Brand
ATEN
Model
CS1732B
Details
Type
D-Sub, USB
PC Connectors
Audio 2 x stereo speaker; 2 x Microphone Peripherals 2 x USB 2.0 Keyboard, Mouse, and Monitor 2 x SPDB15 (VGA / SVGA)
Console Connectors
Mouse USB Keyboard USB Monitor 1 x HDB-15 Female Audio 1 x stereo speaker; 1 x Microphone
Computer Connections
2 Ports
Monitor Connections
1 Port
Video Resolution
2048 x 1536 (Max.)
PC Selection
Push Buttons/Hot Keys
AutoScan Interval
5 sec.
LED Indicators
Selected 2 On Line 2 (Green) USB Peripherals 2 (Orange)
Environmental
Temperature
Operating 4 - 40 C Storage -20 - 60 C
Humidity
0% to 80%,Non-Condensing
Features
Audio Features
2.1 surround sound audio
Power Features
5V DC 2.1A
Features
2-port KVMP switch with USB 2.0 support and 2.1 surround sound audio One console controls 2 computers and two additional USB devices 2-port USB 2.0 compliant hub built in - Dual interface supports computers with PS/2 or USB keyboard and mouse configurations Audio-enabled full bass response provides a rich experience for 2.1 surround sounds systems Console audio ports on front panel - ideal for IP phone use Supports both USB and PS/2 keyboards and mice for flexible configurations available with the included USB to PS/2 Independent switching of KVM, USB, and Audio. Maximum video resolution ; 2048 x 1536; DDC2B. Supports widescreen Monitors Computer selection via front panel pushbuttons, OSD (On Screen Display), or Hotkeys Multiplatform support; Windows 2000/XP/Vista, Linux, Mac, and Sun Console mouse port emulation bypass feature supports programmable mice Display Emulation Technology - reads and remembers the monitor's display parameters to maintain optimum display settings when switching between computers Complete keyboard emulation for error free booting - Sun/Mac keyboard support and emulation* Auto Scan Mode for sequentially monitoring all computers LED display for easy status monitoring
Dimensions & Weight
Dimensions
7" x 2.25" x 9.5"
Weight
1.0 lbs.
Additional Information
First Listed on Newegg
August 22, 2025
Customer Reviews of the ATEN CS1732B
There are no reviews yet.
Do you own this product?
Warranty & Returns
Warranty, Returns, And Additional Information
Warranty
Please contact the Seller directly for warranty information. Warranty information may also be found on the Manufacturer's website.
