Athena Power AP-PS2MK10P868 1000W 80 PLUS Platinum Industrial PS2 ATX 3.1 Power Supply

Athena Power AP-PS2MK10P868 1000W 80 PLUS Platinum Industrial PS2 ATX 3.1 Power Supply

The AP-PS2MK10P868 is a high-performance 1000W industrial-grade PS2 power supply designed for workstations, industrial PCs, edge servers, and GPU-intensive platforms. Compliant with ATX 3.1 and PCIe 5.0 standards, it features a 12V-2x6 (H++) GPU connector for stable high-current output to support demanding GPUs and compute workloads.

1. Power Output: 1000W continuous output with low ripple for professional and industrial applications
2. Efficiency: 80 PLUS Platinum certified, up to 92%
3. Connectors: 24-pin ATX (20+4) ×1, EPS 8-pin ×1, 8(4+4)-pin CPU ×1, PCIe 6+2 ×1 ×2, PCIe 12V-2x6 (H++) ×1, SATA ×4 + Molex ×1 ×2; Cable color: black
4. Cooling: Dual 80mm ball-bearing fans with smart thermal control for reliable temperature management
5. Electrical Specs: Input voltage 100240V AC, 50/60Hz; Active PFC; Hold-Up 17ms; Rise Time <20ms; MTBF 100,000 hours @25°C
6. DC Output Ratings: +3.3V 18A, +5V 18A, +12V1/12V2 82A, -12V 0.5A, +5VSB 3.0A
7. Mechanical Specs: 200 × 100 × 69.7mm / 7.87 × 3.93 × 2.75in; Weight: 5.0lbs; Operating Temp: 050°C; Storage Temp: -2080°C
8. Compliance: IEC/UL/EN 62368-1, RoHS, CE/FCC compliant, industrial low ripple design
9. Warranty: 5-Year Limited Manufacturer Warranty
10. Applications: AI / Deep Learning Workstations, Industrial Computing Systems, Edge Servers, High-End Gaming Systems, GPU Compute Platforms, Mission-Critical Environments

The AP-PS2MK10P868 combines high power, Platinum-level efficiency, industrial reliability, and advanced cooling in a compact PS2 form factor, making it ideal for GPU-intensive and mission-critical professional computing systems.
