MAIN OVERVIEW FEATURES: Cable Type: Category 5eCable Characteristic: Patch CableCable Length: 10 ftConnector on First End: 1 x RJ-45 Male NetworkConnector on Second End: 1 x RJ-45 Male NetworkColor: BlackLimited Warranty: Lifetime
Learn more about the Belkin A3L791-10-BLK
Model
Brand
Belkin
Model
A3L791-10-BLK
Type
Consumer Electronics
Details
Cat
5E
Connector A
RJ45
Connector B
RJ45
Length
10 ft.
Color
Black
Shielded
No
Features
Features
Characteristic Impedence: 100±15O @ 1 ~ 100MHz Conductor Construction: Bare Stranded Copper Conductor Resistance: 89.2O/km/20°C max Conductor Size: 24AWG x 4pairs Connector Type: 50 micron gold-plated connector Description: Cat5e UTP Stranded Patch Cable , ISO/IEC 11801; TIA/EIA-568-B.2 Dielectric Strength: AC 1.75kV/0.15sec Flame Retardant Test: CM Insulation Material: HDPE Jacket Diameter: 5.5±0.15mm Jacket Material: PVC Mutual Capacitance: 56pF/m max Propagation Delay: 538nS/100m max @ 100MHz Rating: 75°C, 300V Spark Test: 2.5kV Standards Compliance: ISO/IEC 11801; TIA/EIA-568-B.2 Structural Return Loss: 19.0dB min at 100MHz
Exceeds the performance requirement of Category 5e.
Perfect in conjunction with 10 and 100 Base-T networks.
50-micron gold plated connectors to insure a clean and clear transmission.
