Brand | Bountiful |
---|---|
Model | BWRG1000 |
Standards | IEEE 802.11g/b, 802.3/3u |
---|---|
Device Management | Web-based UI with easy setup wizard, CLI-like Teinet UI |
Security | WEP with 64/128-bit of key WEP with 802.1x/RADIUS authentication WPA with 802.1x/RADIUS authentication & key management WPA with Pre-Shared Key (PSK) WPA2 Radius Layer 2/3/4 access control Layer 2/3/4 firewall & packet filtering DoS prevention Intrusion detection Built-in Firewall: NAT/NAPT |
WPA | WPA2 |
WAN Ports | 1 x 10/100M |
LAN Ports | 4 x 10/100M |
LEDs | System: Power/Fault WAN: Link/Activity LAN: Link/Activity WLAN: Link/Activity |
Wireless Data Rates | Up to 54Mbps |
Operating Range | Due to increased transmit power and sensitivity, range will be 2 to 4 times that of standard access points. Ranges vary based upon numerous environmental factors and unit configuration, so individual performance may vary significantly. |
Modulation | 802.11b: CCK 802.11g: OFDM |
Antenna | Detachable di-pole, 2.2 dBi, R-SMA |
Channels | 11 Ch (2.412-2.462GHz) USA 13 Ch (2.412-2.472GHz) Europe 14 Ch (2.412-2.83GHz) Japan |
Transmitted Power | 802.11b: 29 dBm ± 1dB 802.11g: 27 dBm ± 1dB |
Receiver Sensitivity | 802.11b: 1 Mbps; -95 dBm 11 Mbps; -90 dBm 802.11g: 6 Mbps; -92 dBm 54 Mbps; -73 dBm |
Interface | Ethernet Port |
VPN support | VPN pass through (PPTP/IPSec) |
Power Adapter | 5Vdc @ 4A |
Wireless Adapter included | No |
Dimensions | 8.5" x 6.6" x 1.8" |
Weight | 1.0 lbs. |
Temperature | 0 to 35 °C |
Humidity | 10% - 90% (Non-Condensing) |
Features | IP/Ethernet Port Forwarding WAN port MAC adjustment DNS proxy, Dynamic DNS DHCP server DHCP/BOOTP client NAT/NAPT Virtual server DMZ hosting VLAN support WiFi multimedia WDS Bridging/Repeating |
---|
Date First Available | July 18, 2007 |
---|
