CISCO AIR-CT2504-25-K9 2500 Series Wireless Controller for up to 25 Cisco access points

Be the first to review this product...

AIR-CT2504-25-K9
Wireless LAN Controller

Overview

Specs

Reviews

Any questions? Our AI beta will help you find out quickly.

Try me now

The Cisco 2500 Series Wireless Controller enables systemwide wireless functions in small to medium-sized enterprises and branch offices. Designed for 802.11n performance, Cisco 2500 Series Wireless Controllers are entry-level controllers that provide real-time communication between Cisco Aironet access points to simplify the deployment and operation of wireless networks As a component of the Cisco Unified Wireless Network, this controller delivers centralized security policies, wireless intrusion prevention system (wIPS) capabilities, award-winning RF management and quality of service (QoS) for voice and video. Delivering 802.11n performance and scalability the 2500 Series provides low total cost of ownership and flexibility to scale as network requirements grow.

Cisco 2504 Wireless Controller With 25 Ap Licenses The Cisco 2500 Series Wireless Controller Enables System Wide Wireless Functions In Small To Medium-Sized Enterprises And Branch Offices. Designed For 802.11N Performance Cisco 2500 Series Wireless C

Model
Brand	CISCO
Model	AIR-CT2504-25-K9

Details
Type	Wireless LAN Controller
Specifications	Scalability: Supports 25 access points. Wireless Standards: IEEE 802.11a, 802.11b, 802.11g, 802.11d, WMM/802.11e, 802.11h, 802.11n. Wired/Switching/Routing: IEEE 802.3 10BASE-T, IEEE 802.3u 100BASE-TX specification, 1000BASE-T, and IEEE 802.1Q VLAN tagging. Encryption: WEP and Temporal Key Integrity Protocol-Message Integrity Check (TKIP-MIC): RC4 40, 104 and 128 bits (both static and shared keys). Advanced Encryption Standard (AES): CBC, CCM, Counter Mode with Cipher Block Chanining Message Authentication Code Protocol (CCMP). DES: DES-CBC, 3DES. Secure Sockets Layer (SSL) and Transport Layer Security (TLS): RC4 128-bit and RSA 1024- and 2048-bit. DTLS: AES-CBC Interfaces: Network: Four 1 Gbps Ethernet (RJ-45) Console port: RJ-45 connector LED indicators: Link Activity (each 1G port), Power, Status, Alarm Management Interfaces: Designed for use with Cisco Wireless Control System Web-based: HTTP/HTTPS individual device manager Command-line interface: Telnet, SSH, serial port Power adapter: Input power: 100 to 240 VAC; 50/60 Hz Dimensions: 1.73" x 8.00" x 6.75" Weight: 3.50 lbs. (with power supply)

Features
Features	Security Standards: WiFi Protected Access (WPA) IEEE 802.11i (WPA2, RSN) RFC 1321 MD5 Message-Digest Algorithm RFC 1851 The ESP Triple DES Transform RFC 2104 HMAC: Keyed Hashing for Message Authentication RFC 2246 TLS Protocol Version 1.0 RFC 2401 Security Architecture for the Internet Protocol RFC 2403 HMAC-MD5-96 within ESP and AH RFC 2404 HMAC-SHA-1-96 within ESP and AH RFC 2405 ESP DES-CBC Cipher Algorithm with Explicit IV RFC 2406 IP Encapsulating Security Payload (ESP) RFC 2407 Interpretation for ISAKMP RFC 2408 ISAKMP RFC 2409 IKE RFC 2451 ESP CBC-Mode Cipher Algorithms RFC 3280 Internet X.509 PKI Certificate and CRL Profile RFC 3602 The AES-CBC Cipher Algorithm and Its Use with IPsec RFC 3686 Using AES Counter Mode with IPsec ESP RFC 4347 Datagram Transport Layer Security RFC 4346 TLS Protocol Version 1.1 Management: SNMP v1, v2c, v3 RFC 854 Telnet RFC 1155 Management Information for TCP/IP-Based Internets RFC 1156 MIB RFC 1157 SNMP RFC 1213 SNMP MIB II RFC 1350 TFTP RFC 1643 Ethernet MIB RFC 2030 SNTP RFC 2616 HTTP RFC 2665 Ethernet-Like Interface types MIB RFC 2674 Definitions of Managed Objects for Bridges with Traffic Classes, Multicast Filtering, and Virtual Extensions RFC 2819 RMON MIB RFC 2863 Interfaces Group MIB RFC 3164 Syslog RFC 3414 User-Based Security Model (USM) for SNMPv3 RFC 3418 MIB for SNMP RFC 3636 Definitions of Managed Objects for IEEE 802.3 MAUs Cisco private MIBs High Performance: Wired-network speed and nonblocking performance for 802.11n networks. RF Management: Provides both real-time and historical information about RF interference impacting network performance across controllers, via systemwide Cisco CleanAir technology integration.

Additional Information
First Listed on Newegg	December 19, 2011
