Code CR3621-PKCXB 3600 (CR3600) Bluetooth Barcode Scanner

Be the first to review this product...
  • 1D/2D
  • Scanner with bluetooth
  • Palm style no handle
  • Includes USB charging cable
  • Battery, and charging station
  • Color: Gray
  • IP55 housing
Specs
Reviews
avatar

Any questions? Our AI beta will help you find out quickly.

Try me now

Learn more about the Code Corporation CR3600

General
Brand Code
Model CR3600
Part Number CR3621-PKCXB
Form Factor Palm style no handle
Scan Engine 2D/1D
Connectivity
Included Cables Includes USB charging cable
Scan Performance
Light Source Sunlight: Up to 9,000ft-candles/96,890 lux
Resolution High Density Field: 960 x 640
Wide Field: 960 x 640
Depth of Scan Field High Density Field: 30° horizontal by 20° vertical
Width of Scan Field 50° horizontal by 33.5° vertical
Pitch ± 60° (from front to back)
Yaw ± 60° from plane parallel to symbol (side-to-side)
Print Contrast Ratio (Minimum) 25% (1D symbologies) or 35% (2D symbologies) absolute dark/light reflectance differential, measured at 650 nm
Electrical
Input Voltage Reader @ 4.2vdc (mA):
Typical = 179 mA
Peak = 331 mA
Idle = 101 mA
Sleep = 25 mA

Charging Station with Embedded CodeXML Modem:
USB max charge rate = 542 mA
USB trickle charge rate = 157 mA

Charging Station with External CodeXML M3 Modem:
USB max charge rate = 495 mA
USB trickle charge rate = 123 mA
Mechanical
Color Gray
Dimensions 1.40" X 5.10" x 2.00"
Charging Station: 2.40" x 4.50" x 3.30"
Weight Palm Reader: 0.34 lb.
Battery: 0.11 lb.
Charging Station with Embedded Modem Weight: 0.27 lb.
Charging Station without Embedded Modem Weight: 0.24 lb.
Features
Features Operating Temperature: -20° to 55° C / -4° to 131° F
Storage Temperature: -30° to 65° C / -22° to 150° F
Humidity: 5% to 95% non-condensing
Additional Information
First Listed on Newegg January 18, 2016

Warranty & Returns

Warranty, Returns, And Additional Information

Warranty

  • Limited Warranty period (parts): 1 year
  • Limited Warranty period (labor): 1 year
