Question 1

Where is the power button?

Accepted Answer

It is on the top of the case. It lights up white.

Question 2

Does this case come with a reset button for the motherboard?

Accepted Answer

If you mean does it come with two buttons like the older (probably 10 plus years) cases where one was the power button and the second rebooted the system, no it does not. To reset an unresponsive system with this case, you will need to hold down the power button for approximately 10 seconds, like most notebooks. This should shut off the power, then you can boot the computer again.

Question 3

I am considering this case for a new build. It doesn't look like my 240mm coolermaster liq cooler I planned for will work on top. I don't think it will be efficient in front as they vent out, blockng flow, am I correct?

Accepted Answer

Flip the fans to the other side and front mount it. The top vents are offset so it can possibly work too.  However, top mounting can have clearance issues with some types of RAM sticks that are too tall or too wide since the mobo sits way up on the tray.

Question 4

What are the fan sizes for both the rear and front fans? Is it all 120mm or is the rear fan just a 80mm?

Accepted Answer

The rear fan is 80mm.

Question 5

how to install the dvd-rom?, the clip doesnt to hold onto my rom

Accepted Answer

yea, it does work but is a real puzzle even for an engineer.  There are holes for screws so just use a screw instead.  I recall I had less trouble mounting the dual fan liquid cooler in the front than  to lock down the dvd.

Question 6

I only have usb2 headers on my motherboard, can I use and adapter to enable front panel usbs ?

Accepted Answer

yes, several types of PCIe USB3 adapters have those 19 (or 20) pin connectors for front panel USB3.  Vantec pc365 "PCIe-X1" worked with my xps-435mt mATX motherboard.

Question 7

Are the fans pwm?

Accepted Answer

Yes, it’s have 3 pins connector

Question 8

Will this fit a Cooler Master Hyper 212 EVO - CPU Cooler?

Accepted Answer

Hello,

Thank you for contacting us in regards to your question.

This case will not support the Hyper 212. This case support for anything less than 157mm height. Hyper 212 is at 159mm.

You can check out the DEEPCOOL GAMMAXX 400 CPU Air Cooler (item # N82E16835856005), which is basically a shorter Hyper 212.

Thank you,
Newegg Support

Question 9

Will this fit the Cooler Master Hyper 212 EVO - CPU Cooler?

Accepted Answer

Hello,

Thank you for contacting us in regards to your question.

It would not fit. The Hyper Evo 212 is barely 2mm too tall to fit into the case.

Thank you and have a nice day!
Newegg Support
