The first ever CPU heat sink to utilize vertical vapor chamber cooling and combine it with heat pipe technology, TPC 812 is prepared to handle the massive heat generated by overclocking and benchmarking. Vertical vapor chamber working in tandem with heat pipes and a specialized heat sink and fin design allow the TPC 812 to outperform the competition.
![]() |
|
![]() |
VERTICAL VAPOR CHAMBER The first ever vertical vapor chamber created for tower heat sink. Traditional vapor chamber are used in graphics card to help dissipate the heat faster, with the new vertical vapor chamber it can help TPC 812 to dissipate heat faster than competition. |
![]() |
|
![]() |
SPECIAL FIN DESIGN The new fin design can help concentrate the cold airflow directly at the heat pipe to dissipate heat faster. |
![]() |
|
![]() |
UNIVERSAL MOUNTING SOLUTION Supports the latest sockets from Intel and AMD |
![]() |
Model | RR-T812-24PK-R1 |
CPU Socket |
Intel Socket: LGA 2011 / 1366 / 1156 / 1155 / 775 * AMD Socket: FM2 / FM1 / AM3+ / AM3 / AM2+ / AM2 |
CPU Support |
Intel: Core™ i7 Extreme / Core™ i7 / Core™ i5 / Core™ i3 / Core™2 Extreme / Core™2 Quad / Core™2 Duo / Pentium / Celeron AMD: FX-Series / A-Series / Phenom™ II X4 / Phenom™ II X3 / Phenom™ II X2 / Phenom™ X4 / Phenom™ X3 / Athlon™ II X4 / Athlon™ II X3 / Athlon™ II X2 / Athlon™ X2 / Athlon™ / Sempron™ |
Dimension | 138 x 103 x 163mm (5.4 x 4.1 x 6.4 in) |
Heat Sink Dimensions | 134 x 74 x 158 mm (5.3 x 2.9 x 6.2 in) |
Heat Sink Material |
Copper Base / 2 Vapor Chambers 6 Heatpipes / Aluminum Fins |
Heat Sink Weight | 826g (1.83 lb) |
Heat Pipes Dimensions | ø6mm |
Fan Dimension | 120 x 120 x 25mm (4.7 x 4.7 x 1 in) |
Fan Speed |
600 – 2,400 RPM (PWM) ± 10% (1,600 RPM with Silent Mode Adapter) |
Fan Airflow |
19.17 - 86.15 CFM ± 10% (59.54 CFM @ 1600RPM) |
Fan Air Pressure |
0.31 – 4.16 mm H2O ± 10% (1.99mm H2O @ 1600RPM) |
Fan Life Expectancy | 40,000 hrs |
Fan Noise Level (dB-A) | 19 - 40 dBA |
Bearing Type | Long Life Sleeve Bearing |
Connector | 4-Pin |
Fan Rated Voltage | 12 VDC |
Fan Rated Current | 0.2A |
Power consumption | 2.4W |
Maximum TDP | 300W |
Fan Weight | 152g (0.34 lb) |
Notice | * Supplied accessories may differ by country or area. Please check with your local distributor for further details. |
Warranty | 2 years |
UPC Code | 884102015229 |
Pros: Very nice looking CPU cooler and keeps my i7 fairly cool. Has the option of changing the fan to one of your choosing and has the option to add a second fan for push/pull config.
Cons: Cools pretty as well as my old cooler, the Prolimatech Megahalems Rev.B CPU Cooler with the same fans. Also using the same fans from previous cooler, the clearance on the memory was worse than my old cooler. Just barely clips the fan on over my Gskill Ripjaws Lastly the U-shaped holes for the screws to go through on the backplate were not big enough for some of the screws, so I had to bend it a little bit to get the screws to fit.
Overall Review: I was hoping the vapor chambers would add a somewhat noticeable improvement in cooling but I was wrong. i7-2600k @ 4.5 GHz Idle: 85-90 °F Load: 155-162 °F
