D-Link DWL-G680 High-Powered Wireless 108G Notebook Adapter

Name: D-Link DWL-G680 High-Powered Wireless 108G Notebook Adapter
Brand: D-Link
SKU: N82E16833127168
Rating: 5 (10 reviews)

Specs

Reviews (10)

Any questions? Our AI beta will help you find out quickly.

Try me now

Learn more about the D-Link DWL-G680

Model
Brand	D-Link
Model	DWL-G680

Details
Type	802.11b/g CardBus Wireless Adapter
Standards	IEEE 802.11b/g,IEEE 802.1x
Max Data Rates	108Mbps
LEDs	Link, Activity
Security	WEP 64/128bit, WPA-Personal, WPA-Enterprise, WPA2-Personal, WPA2-Enterprise
Frequency Band	2.4 – 2.5GHz
Modulation	802.11b: DQPSK, DBPSK, DSSS, CCK 802.11g: BPSK, QPSK, 16QAM, OFDM
Transmitted Power	802.11b Typical 21dBm at 11, 5.5, 2 an 1Mbps 802.11g Typical +15 - 18dBm for 54Mbps Typical +16 - 19dBm for 48Mbps Typical +17 - 20dBm for 36Mbps Typical +18 - 21dBm for 24, 18, 12, 9, 6Mbps
Sensitivity	802.11b Typical -84dBm for 11Mbps @ 8% PER Typical -90dBm for 2Mbps @ 8% PER 802.11g Typical -87dBm for 6Mbps @ 10% PER Typical -86dBm for 9Mbps @ 10% PER Typical -85dBm for 12Mbps @ 10% PER Typical -83dBm for 18Mbps @ 10% PER Typical -80dBm for 24Mbps @ 10% PER Typical -76dBm for 36Mbps @ 10% PER Typical -71dBm for 48Mbps @ 10% PER Typical -66dBm for 54Mbps @ 10% PER
Antenna	Integrated Printed PCB antenna w/ dual diversity
Temperature	0ºC to 55ºC
Humidity	10-90%, Non-Condensing

Features
Features	Supports Both Personal and Enterprise Versions of WPA and WPA2 Wireless Security Business-Class WLAN Utility Including Multiple SSID per Profile and Silent Installation Feature Wi-Fi and Microsoft WHQL Certified

Dimensions & Weight
Dimensions	2.0" x 1.8" x 0.2"
Weight	0.12 lbs.

Packaging
Package Contents	DWL-G680 Resource Disk Install Guide

Additional Information
First Listed on Newegg	June 14, 2005

Return for refund within: 30 days

Return for replacement within: 30 days
