Darkside 2mm (5/64") High Density Cable Sleeving - Sky Blue, 1ft (DS-0839)
- DarkSide 2mm (5/64") high density cable sleeving in Sky Blue with an ultra tight weave, typically used for single wires of standard AWG18 power supply cables
- Custom cut to order and priced per foot
- DarkSide 2mm (5/64") high density cable sleeving in Sky Blue with an ultra tight weave, typically used for single wires of standard AWG18 power supply cables
- Length: 1ft
- Included: Custom cut to order and priced per foot.
Any questions? Ask CelesteSM will help you find out quickly.
DarkSide 2mm (5/64") high density cable sleeving in Sky Blue is braided sleeving with an ultra tight weave for custom cable modding. The 2mm size is typically used to sleeve single wires of standard AWG18 power supply cables, one sleeve per wire.
Properties
- Type: High density braided cable sleeving
- Size: 2mm (5/64")
- Expands to: about 5 mm
- Typical use: Single wires of standard AWG18 power supply cables
- Color: Sky Blue
- Sold by: The foot, custom cut
Ultra tight high density weave
DarkSide high density sleeving is woven with an ultra tight weave for custom cable modding. The dense braid covers the wires underneath, so a cable set of mixed black, red and yellow wires turns into neat, even runs in the color you choose.
Made for single AWG18 wires
The 2mm size is typically used to sleeve single wires of standard AWG18 power supply cables, one sleeve per wire. At rest it measures 2 mm and it opens up to about 5 mm, so it slides over an AWG18 wire and then closes around it.
Cut to the length you need
ModMyMods custom cuts this sleeving to order and prices it per foot: the length you order is the length you receive. Add up the lengths of all the wires you want to sleeve and order the total.
Working with braided sleeving
- Pushed together, braided sleeving widens; pulled, it narrows and closes around the wire. That is how it slides over a wire and then sits snug.
- For single-wire sleeving, take the terminal out of the connector, slide the sleeve over the wire, finish the ends and put the terminal back in its original position.
- Finish the cut ends so they do not fray, usually with a short piece of heat shrink tubing at each end.
- Plan a little extra length per wire for finishing the ends.
Other sizes
DarkSide high density sleeving is also available in 4mm (5/32") for small bundles such as 2-3 fan wires or LED wires, in 6mm (1/4") for a few power wires or a 4-wire RGB LED cable, and as 10mm (3/8") SATA sleeving for SATA data cables.
Technical data
- Brand: DarkSide (DazMode)
- Type: High density braided cable sleeving
- Nominal size: 2 mm (5/64", 0.078")
- Maximum expanded size: about 5 mm
- Typical use: Single wires of standard AWG18 power supply cables
- Color: Sky Blue
- Sold by: The foot, custom cut to order
Notes
- ModMyMods carries DarkSide 2mm high density sleeving in Acid Yellow UV, Aquamarine Blue, Arabica Brown, Arctic Camo, Black, Commando UV, Coral UV, Dark Blue UV, Frosted White, Gold II, Graphite, Green UV, Gun Metal, Lava II UV, Metal Jacket, Metallic Red, Opaque Red, Orange II, Red UV, Sky Blue, Titanium Gray, Violet UV, White and Yellow II UV. This listing is Sky Blue.
- Colors on screen can look slightly different from the sleeving in hand, especially the UV colors, which are photographed both in normal light and under UV light.
In the box
- 1x DarkSide 2mm high density cable sleeving, Sky Blue, cut to the length ordered (per foot)
