Dataram 8GB DDR3 SDRAM Memory Module

DTM64316G is a registered 1Gx72 memory module, which conforms to JEDEC's DDR3, PC3-10600 standard. The assembly is Dual-Rank. Each Rank is comprised of eighteen 512Mx4 DDR3-1333 Micron SDRAMs. One 2Kbit EEPROM is used for Serial Presence Detect and a combination register/PLL, with Address and Command Parity, is also used.

Both output driver strength and input termination impedance are programmable to maintain signal integrity on the I/O signals in a Fly-by topology.

A thermal sensor accurately monitors the DIMM module and can prevent exceeding the maximum operating temperature of 95C.

Features

* Product Type: RAM Module
* Memory Standard: DDR3-1333/PC3-10600
* Memory Technology: DDR3 SDRAM
* CAS Latency: CL9
* Memory Size: 8 GB
* Brand Name: Dataram
* Form Factor: DIMM
* Memory Speed: 1333 MHz
* Error Checking: ECC
* Number of Pins: 240-pin
* Signal Processing: Registered
* Product Type: RAM Module
* Green Compliant: Yes
* Green Compliance Certificate/Authority: RoHS
* Memory Standard: DDR3-1333/PC3-10600
* Width: 1.2"
* Memory Technology: DDR3 SDRAM
* CAS Latency: CL9
* Memory Size: 8 GB
* Brand Name: Dataram
* Compatibility:

Intel Server Board S5520HC

* Form Factor: DIMM
* Length: 5.3"
* Memory Speed: 1333 MHz
* Product Model: DTM64316G
* Product Name: 8GB DDR3 SDRAM Memory Module
* Error Checking: ECC
* Number of Modules: 1 x 8 GB
* Number of Pins: 240-pin
* Signal Processing: Registered
* Limited Warranty: Lifetime
* Thickness: 50 mil
