Technical parameters:
Camera sensor: 1/ 2.3 inch CMOS
Camera pixels 12 million
Lens field of view: 150 °
Equivalent focal length: 14.66 mm
Aperture: F/ 2.8
Focus mode: FF
Focus range: 0.6 metres to infinity
ISO range: 100 - 12800
Shutter speed: 1/50 - 1/8000 s
Shooting mode: Single shot
Photo size: 3840 x 2160
Photo format: JPEG
Video Resolution: 4K: 3840 x 2160@50/60fps
FHD: 1920 x 1080@50/60/100/120fps
Video format: MP4/MOV (MPEG-4 AVC/H. 264, HEVC/H. 265)
Video Maximum Bitrate: 120Mbps
Colour Mode: Standard Mode D-Cinelike
Electronic stabilisation: Support
Support file system: exFAT (recommended), FAT32
Head Structure: Tilt -65° to 70
Maximum control speed: 60°/s
Amount of angular jitter: ± 0.01 ° (stabilisation mode)
Tilt correction: Supported, max. 10° stabilisation angle
Vehicle take-off weight: 795g
Vehicle size: 255 × 312 × 127 mm (unfolded), 178 × 232 × 127 mm (folded)
Diagonal axis distance: 245 mm
Maximum ascent speed: Unrestricted (M-stop), 15m/s (S-stop), 8m/s (N-stop)
Maximum descent speed: Unrestricted (M stop), 10m/s (S stop), 7m/s (N stop)
Maximum flight speed: 15m/s (N stop), 27m/s (S stop), 39 m/s (M stop)
Maximum flight altitude: 6000m
Maximum flight time: approx. 20 minutes (windless environment 40 km/h uniform speed flight)
Maximum hovering time: approx. 16 minutes (windless environment)
Maximum range: 16.8 km (windless environment)
Maximum wind level: Class 6 wind
Operating ambient temperature: -10°C to 40°C
Transmit power: 2.400 - 2.4835 GHz, FCC: 31.5 dBm, CE: 20 dBm, SRRC: 20 dBm
Number of antennas: 4 antennas
GNSS: GPS + GLONASS + GALILEO
Hover Vertical Accuracy: ± 0.1 m (when visual positioning is working normally), ± 0.5 m (when GPS is working normally)
Hover Horizontal Accuracy: ± 0.3 m (visual positioning normal operation), ± 1.5 m (GPS normal operation)
Support memory card type: 256GB SD card
Sensing system accurate range: 0.5 - 18 metres
Obstacle deceleration function: effective only when using N-stop
Field of view (FOV): 56° horizontal, 71° vertical
ToF effective measurement height: 10 metres
Accurate Hover Height Range: 0.5 - 15 metres
Visual Hover Range: 0.5 - 30 metres
