2Pcs STM32F411CEU6 Development Board STM32F4 Core STM32F411CEU6 Module System Board Learning Board 100Mhz Freq 128KB RAM 512KB ROM for Programming
- Experience the power of the ARM Cortex M4 with this STM32F411CEU6 Development Board, featuring a blazing fast 100Mhz frequency and zero-wait state access to 512KB ROM and 128KB RAM for seamless programming
- Unlock endless possibilities with the STM32F4 Core STM32F411CEU6 Module System Board, equipped with FPU floating-point unit for efficient calculations and a plethora of interfaces including USART, I2C, SPI, and USBFS for versatile connectivity options
- Dive into the world of embedded systems with this Learning Board, boasting 20 Pin 2.54mm I/O interfaces, 4 Pin 2.54mm SW debugging interface, and user-friendly buttons like KEY (PA0), NRST, and BOOT0 for convenient operation and development
- Stay powered up and connected with the 3.3V-5V power input, 3.3V LDO with a maximum output current of 100mA, and a USB-C interface with built-in diode to prevent power backflow, along with high-speed and low-speed crystal oscillators for reliable performance
- Elevate your programming projects with the STM32F411CEU6 Development Board, featuring a SPI Flash for additional storage options, 12-bit ADC, 12-bit 5 S for accurate measurements, and 32.768K 6pF low-speed crystal oscillator for precise timing control
+
+
Overview
Specs
Reviews
Any questions? Ask CelesteSM will help you find out quickly.
Try me now
ARM Cortex M4
Zui operates at a high frequency of 100MHz, with zero waiting for memory access
FPU Floating Point Computing Unit
storage
512KB ROM flash program memory
128KB SRAM Static Random Access Memory
SPI Flash (solder mask)
Interface and buttons
USART x 3, I2C x 3, SPI x 5,USBFS x 1
ADC x 1(10),12S x 5,CRC x 1,TIM x 8
20 Pin 2.54mm spacing I/O interface x 2
4 Pin 2.54mm spacing SW debugging interface x 1
USBC (typeC) interface x 1
User key KEY (PAO) x 1
Reset button NRST x 1
BOOT0 button x 1
Clock and power supply:
3.3V-5V power input, 3.3V LDO MAX output current of 100mA
Using USB-C interface and diodes in series to prevent power backflow
25MHzpF high-speed crystal oscillator
32.768K 6pF low-speed crystal oscillator
