Brand | ECS |
---|---|
Model | BAT-I(1.0)/J2900 |
Combo Type | Motherboard / CPU / VGA Combo |
CPU | Intel Bay Trail J2900 |
---|---|
With Cooler | Yes |
Supported CPU Technologies | Hyper-Threading Technology |
---|
Number of Memory Slots | 1x204pin SO-DIMM |
---|---|
Maximum Memory Supported | 8GB |
PCI Express x1 | 1 x PCI Express x1 |
---|---|
Mini Card Slots | 1 x Mini PCI Express for Wi-Fi /Blutooth modules |
SATA | 2 x SATA 3.0Gb/s |
---|
Onboard Video Chipset | Intel HD Graphics |
---|
Audio Chipset | VIA VT1705 |
---|---|
Audio Channels | 6 Channels |
LAN Chipset | Realtek RTL8111G |
---|---|
LAN Speed | 10/100/1000Mbps |
PS/2 | 1 x PS/2 Keyboard 1 x PS/2 mouse |
---|---|
Video Ports | 1 x D-Sub |
HDMI | 1 x HDMI |
USB 1.1/2.0 | 4 x USB 2.0 |
USB 3.0 | 1 x USB 3.0 |
Audio Ports | 3 Ports |
Onboard USB | 2 x USB 2.0 |
---|---|
Other Connectors | 1 x 4-pin CPU_FAN connector with smart fan 1 x 4-pin SYS_FAN connector with smart fan 1 x Front Panel MIC/Speaker out header 1 x Front Panel switch/LED header 1 x CLR_CMOS header 2 x Serial port header (COM) 1 x Parallel port header (LPT) 1 x LVDS connector (optional) |
Features | Applied Solid Capacitor for CPU VRM to ensure a longer lifespan for system ECS Durathon Technology ensure the stability, reliability and performance of system. (Triple Density PCB; Extreme Temp Resistance; 1.5K Marathon Test; Superior Solid CAPs) Dual Display design for multiple output support Integrated Printer (LPT) port / header to expand functionality Microsoft Windows 8 Certified Intel VRD 12 Ready Supports DirectX 11 to enhance graphical performance Supports HDMI 1.4a Technology ( resolution up to 1920X1200 ) and HDCP function ECS Intelligent EZ Utility : eBLU, eDLU, eSF Free Bundle: Norton Internet Security ,CyberLink PowerDVD, CyberLink PowerDirector 9, Muzee, Google Chrome, Magix with trial version |
---|
Form Factor | Mini ITX |
---|---|
Dimensions (W x L) | 6.7" x 6.7" |
Date First Available | May 06, 2014 |
---|
