Elo Touch Solutions E343671 Black 31.5" USB PCAP (TouchPro Projected Capacitive) 3263L 32-inch Full HD Open-Frame, TouchPro PCAP (Clear with Anti-friction) 425 cd/m2 3000:1
- 3000:1
- USB
- 178° (H) / 178° (V)
+
+
Learn more about the Elo Touch Solutions E343671
| Brand | Elo Touch Solutions |
|---|---|
| Model | E343671 |
| Cabinet Color | Black |
| Touchscreen Type | PCAP (TouchPro Projected Capacitive) |
|---|---|
| Panel | Active matrix TFT LCD (LED) |
| Screen Size | 31.5" |
| Display Type | FHD |
| Aspect Ratio | 16:9 |
| Resolution | 1920 x 1080 |
| Refresh Rate | 60Hz |
| Viewing Angle | 178° (H) / 178° (V) |
| Display Colors | 16.7 Million |
| Brightness | 425 cd/m2 |
| Contrast Ratio | 3000:1 |
| Response Time | 8ms |
| Touchscreen Interface | USB |
|---|---|
| Connectors | HDMI 1.4 x2 USB 2.0 Type B (for Touch) RJ45 (for optional OSD remote) VGA |
| Video | 2x HDCP-capable HDMI on Type A connector Female DE-15 VGA connector Input Video Horizontal Sync frequency range: 31.5 - 80 KHz Input Video Vertical Sync (frame rate) frequency range: 47 - 63 KHz |
| Power Supply | Input connector (power): IEC 60320-C14 Input signal specifications (power): 100-240VAC 50/60Hz |
|---|---|
| Power Consumption | ON (monitor + AC/DC adapter): 44.3 W SLEEP (monitor + AC/DC adapter): 0.61 W OFF (monitor + AC/DC adapter): 0.20 W |
| VESA Compatibility - Mountable | 400 x 200mm |
|---|---|
| MTBF | 50,000 hours demonstrated |
| Dimensions | 29.42" x 17.82" x 2.16" |
|---|---|
| Weight | 24.17 lbs. |
| Humidity Range | Operating: 20% to 80% Storage: 10% to 90% (38.7°C max wet bulb temperature) |
| Temperature Range | Operating Temperature: Portrait/Landscape Mode: 0°C to 40°C / 32°F to 104°F Tabletop Mode: 0° C to 35° C / 32°F to 95°F Storage Temperature: Portrait/Landscape Mode: -20°C to 60°C / -4°F to 140°F Tabletop Mode: -20° C to 60° C / -4° F to 140° F |
| First Listed on Newegg | June 23, 2022 |
|---|
Warranty & Returns
Warranty, Returns, And Additional Information
Warranty
- Limited Warranty period (parts): 1 year
- Limited Warranty period (labor): 1 year
- Read full details
Return Policies
- Return for refund until: January 31, 2027
- Return for replacement until: January 31, 2027
- This item is covered by Newegg.com's Extended Holiday Return Policy.
- Read full return policy for details.
We want to ensure your holiday shopping this year is hassle-free. That’s why we’re automatically extending our return policies on almost every product! For purchases placed between November 1st, 2026 and December 31, 2026 you will have until January 31, 2027 to return your product.
Manufacturer Contact Info
- Manufacturer Product Page
- Manufacturer Website
- Support Phone: 1-800-557-1458
- Support Email: customerservice@elotouch.com
- Support Website
- View other products from Elo Touch Solutions
LOADING...
LOADING...
The Elo 3263L (E343671) is a 31.5-inch Full HD open-frame touchscreen monitor with USB TouchPro PCAP, suited to POS and kiosk integrators who need a large interactive display. It offers 1920 × 1080 resolution, 425 cd/m² brightness, and a clear, anti-friction touch surface.
Recommended For
- Kiosk and self-service integrators who need a large touch display fitted into a custom enclosure; the 3263L is an open-frame monitor designed for enclosure integration.
- Retail, hospitality, and transportation operators building public-facing self-service stations, where customers need to tap or interact directly with a large screen.
- Installations that need frequent or continuous operation, such as unattended information or ordering kiosks; Elo positions the 3263L for 24/7 use.
- Developers of interactive displays or multi-touch applications who need a large PCAP touch surface, with support for up to 40 touches and touch-through installations behind compatible glass or plastic.
Spec Summary
| Attribute | Value |
|---|---|
| Best For | Touch-enabled point-of-sale and other interactive display installations |
| Panel And Resolution | 31.5-inch active-matrix TFT LCD with LED backlight, Full HD 1920 × 1080 resolution, 16:9 aspect ratio, 16.7 million colors, 425 cd/m² brightness, 3000:1 contrast ratio, and 178° horizontal and vertical viewing angles |
| Refresh Rate And Response | 60 Hz refresh rate with an 8 ms response time |
| Touchscreen | PCAP TouchPro projected-capacitive touchscreen with USB interface |
| Ports And Connectivity | Two HDMI 1.4 inputs with HDCP support, VGA via female DE-15 connector, USB 2.0 Type-B for touch, and RJ45 for an optional OSD remote |
| Video Signal Compatibility | Horizontal sync range: 31.5–80 KHz; vertical sync (frame rate) frequency range: 47–63 KHz |
| Mounting And Dimensions | VESA-mountable at 400 × 200 mm; dimensions are 29.42 × 17.82 × 2.16 inches and weight is 24.17 lb |
| Power | IEC 60320-C14 power input, 100–240 VAC at 50/60 Hz; power consumption is 44.3 W on, 0.61 W in sleep, and 0.20 W off |
| Operating Environment | Operating humidity: 20%–80%; storage humidity: 10%–90% (38.7°C maximum wet-bulb temperature). Operating temperature: 0°C–40°C in portrait/landscape mode or 0°C–35°C in tabletop mode; storage temperature: −20°C–60°C |
| Reliability | MTBF: 50,000 hours demonstrated |
| Model Identifiers | Elo Touch Solutions, model E343671; black cabinet |
