ENCORE ENHWI-2AN3 Wireless Router With Repeater 802.11b/g/n up to 300Mbps/ 10/100 Mbps Ethernet Port x4
- 802.11b/g/n 300Mbps
- 10/100 Mbps Ethernet Port x4
- Repeater function Ready
Specs
Reviews (286)
Any questions? Our AI beta will help you find out quickly.
Try me now
Learn more about the Encore ENHWI-2AN3
| Brand | ENCORE |
|---|---|
| Model | ENHWI-2AN3 |
| Standards | IEEE 802.3/3u, IEEE 802.11b/g, IEEE802.11n Draft 2 |
|---|---|
| Security | 64/128-bits WEP Encryption WPA, WPA2 WPA-PSK, WPA2-PSK MAC address filtering Protocol filtering Domain filtering |
| WPA | WPA2 |
| WAN Ports | 1 x 10/100M |
| LAN Ports | 4 x 10/100M |
| LEDs | Power, WAN: Internet Connection LAN: Wired Local Area Network connection WLAN: Wireless Local Area Network Connection |
| Wireless Data Rates | Up to 300Mbps |
| Operating Range | Indoor: Up to 100m, Outdoor: Up to 300m |
| Modulation | OFDM: BPSK, QPSK, 16-QAM, 64-QAM BPSK, DQPSK, CCK |
| Frequency Band | 2.4 GHz - 2.484 GHz |
| Antenna | 2 x 2dBi dipole antennas with SMA connector |
| Channels | 11 Channels (US, Canada) 13 Channels (Europe) |
| Transmitted Power | IEEE802.11n - MCS7@ 15dBm IEEE802.11g - 6~54 Mbps@ 15dBm IEEE802.11b - 1, 11Mbps@ 16dBm |
| Receiver Sensitivity | IEEE802.11n - MCS0@ -91dBm, MCS7@ -74dBm IEEE802.11g - 6Mbps@ -90dBm,54Mbps@ -70dBm IEEE802.11b - 1Mbps@ -90dBm, 11Mbps@ -87dBm |
| Interface | Ethernet Port |
| Power Supply | Full Range 100-1240VAC. Output 12VDC /1.0 |
| Wireless Adapter included | No |
| Temperature | 0°C - 45°C (32°F - 113°F) |
| Humidity | 15% - 95%, Non-Condensing |
| Features | Setup New Wireless Network - Provides wireless network to your home or office under Router mode Extend Existing Wireless Coverage - Increases coverage and eliminates dead spots under Repeater mode Advanced Wireless Security and Firewalls - Safeguards your data and prevents intruders Dynamic Parental Control - Filters web addresses and keywords to keep harmful content away Create Up to 4 Wireless Networks with 1 Device (multiple SSID) - Setup separate networks for different departments in your office, or provide guest access for visitors at home Two in one product. Can be use as a "Wireless AP Router Mode" or a "Wireless Repeater Mode". Easy and friendly installation guide. Equipped with a "Smart Wizard" software connecting your PC or laptop to the internet in an easy guided installation in a snap Compatible with IEEE 802.11n Draft 2.0 Specifications provides wireless speed up to 300 Mbps data rate Supports up to 4 SSID that can be used to separate your wireless sharing with groups such as Guests, Family Members, Neighbors, etc., each group can have own connection policies. Easy to install, no need to be a geek to get this feature up and running. Supports URL Filtering (or web site address filtering) and Keyword Filtering. This easy to set up feature can be use to control internet access use for Parental Guidance or Parental Control, web site or URL blocking such as specific web sites containing harmful images, etc. Keyword blocking such as harmful words blocking. Backward compatible with IEEE 802.11g high rate standard to provide wireless Ethernet speeds of 54 Mbps data rate Uses the latest MIMO (or Multiple-Output-Multiple-Input) technology for faster and accurate wireless multiple input/output of data streams Supports Bandwidth Control or Priority Queuing, use mostly for bandwidth hungry applications such as Wi-Fi Multimedia, Audio/Video Streaming and much more. |
|---|
| Date First Available | January 25, 2010 |
|---|
Warranty & Returns
Warranty, Returns, And Additional Information
Warranty
- Limited Warranty period (parts): 1 year
- Limited Warranty period (labor): 1 year
- Read full details
Return Policies
- Return for refund within: 45 days
- Return for replacement within: 1 year
- This item is covered by Newegg.com's 45/1 Return Policy. Read full return policy for details.
Manufacturer Contact Info
- Manufacturer Product Page
- Manufacturer Website
- Support Phone: 1-626-363-7600
- Support Email: [email protected]
- Support Website
