| Standards | IEEE 802.11b/g/n on 2.4 GHz Radio I: 11b/g/n: 2.412-2.472 GHz Data Rate: Up to 300 Mbps on the 2.4 GHz band |
|---|
| Wireless Data Rates | Up to 300Mbps |
|---|
| Security | WEP Encryption: 64/128/152 bit WPA/WPA2 Enterprise (WPA-EAP using TKIP or AES) Hide SSID in Beacons MAC Address Filtering Filter up to 50 MAC addresses Wireless STA (Client) Connection List Reports various information in a timely manner as required by the administrator 802.1x Authenticator |
|---|
| Frequency Band | 2.4 GHz |
|---|
| Antenna | Internal High-Gain Directional Antenna 2.4 GHz (P1) Peak Antenna Gain: 13 dBi Polarization: Linear Horizontal Beam Width: 67° Elevation Beam-Width: 33° VSWR: 1:2.0 2.4 GHz (P2) Peak Antenna Gain: 13 dBi Polarization: Linear Horizontal Beam Width: 61° Elevation Beam-Width: 35° VSWR: 1:2.0 |
|---|
| Transmitted Power | Up to 26 dBm Up to 400 mW Max Power is limited by regulatory power |
|---|
| Interface | Two (2) 10/100 BASE-T Ethernet Ports One (1) Port supports 24V Proprietary PoE Input One (1) Port supports extension of an Internet signal |
|---|
| Buttons | Reset Button |
|---|
| WAN Ports | 2 x 10/100M |
|---|
| Power Supply | Power Source (PoE Injector): 24V/.6A Proprietary Compliant Source Active Ethernet (Power over Ethernet, PoE)
Power Consumption: 7 W |
|---|
