Simultaneously scan two-sided documents with duplex scanning
Rapidly scan up to 70 duplex ppm
Compatible productivity-enhancing software saves time when creating documents
+
+
Overview
Specs
Reviews
EPSON WorkForce DS-70000 Document Scanner
Learn more about the Epson America DS-70000 (B11B204321)
Model
Brand
EPSON
Series
WorkForce
Model
DS-70000 (B11B204321)
Scanning
Type
Duplex
Element Type
CCD
Light Source
ReadyScan LED
Scanning Speed
200 dpi B/W: Up to 70 ppm / 140 ipm with ADF Color: Up to 70 ppm / 140 ipm with ADF
300 dpi B/W: Up to 50 ppm / 100 ipm with ADF Color: Up to 50 ppm / 100 ipm with ADF
600 dpi B/W: Up to 25 ppm / 50 ipm with ADF Color: Up to 12 ppm / 24 ipm with ADF
Color Depth
Input: 16 bit / pixel / color Output: 8 bit / pixel / color
Optical Resolution
600 dpi
Media Handling
Max. Document Size
11.7" x 100" with ADF Flatbed 11.7" x 17"
Automatic Document Feeder (ADF)
Type: Sheet fed 1-pass duplex scanning; Hinge: Free stop, 15 mm max lift Paper Supply: Face up load, face down eject
Capacity: 200 pages (75 g/m2)
Document Sizes: A4, Letter, Legal, B5, A5; Max. Size 11.7" x 100" (ADF), 11.7" x 17" flatbed; Min. Size 2.7" x 4.7"" (ADF)
Paper Weight: 35 g/m2 - 128 g/m2 less than 4" x 6": 60 g/m2 - 190 g/m2
Ports
USB Ports
USB 2.0
Details
Power Requirements
AC 100 - 120V or 220 - 240V, 50 / 60 Hz
Power Consumption
Operating: 79W Ready: 12.5W Sleep: 1.5W
Compatibility
Operating Systems Supported
Windows 8 Windows 7 Windows Vista Windows XP Windows XP Professional x64 Edition Mac OS X 10.5.x, 10.6.x, 10.7.x, 10.8.x
Features
Features
Capture large, 2-sided documents in a single scan - scan documents as large as 11.7" x 100" down to 2.7" x 4.7" through the ADF or 11.7" x 17" on the scanner bed
Remarkable results - 4 line CCD sensor (RGB and black) provides crisp, sharp text
Ultra-fast speeds - one-pass duplex at speeds of 70 ppm /140 ipm1
Work smarter and more efficiently - built-in 200-sheet Automatic Document Feeder, plus auto duplex scanning
Ultrasonic double-feed detector - automatically stops the scanning process if two pages feed together; just separate the pages and continue
Convenient, network scanning capabilities - use the optional networking module and included Document Capture Pro software to scan to any PC on the local network1
Scan directly to popular cloud services - scan to SharePoint, Evernote, Google Docs and more2
Scan to a searchable PDF - save scanned documents as PDF files
Do more with powerful productivity software - includes EPSON Scan, Document Capture Pro (Windows only) and ABBYY FineReader Sprint OCR
One-touch scanning - create up to 30 user-programmable jobs
Dimensions & Weight
Dimensions
25.2" x 18.5" x 11.3" (W x D x H)
Weight
59.2 lbs.
Additional Information
Date First Available
October 09, 2012
Customer Reviews of the Epson America DS-70000 (B11B204321)
