Size
Midi
Type code
LF
Series
D
Mounting position
Vertical
Grade of filtration
5 µm
Condensate drain
Fully automatic
Max. condensate volume
43 ml
Bowl guard
Metal bowl guard
Symbol
00991520
Operating pressure
2 bar ... 12 bar
Standard nominal flow rate
2000 l/min
Corrosion resistance class (CRC)
2 - Moderate corrosion stress
Storage temperature
-10 °C ... 60 °C
Temperature of medium
5 °C ... 60 °C
Ambient temperature
5 °C ... 60 °C
Pneumatic connection 1
3/4 NPT
Pneumatic connection 2
3/4 NPT
Note on materials
RoHS-compliant
Compressed air filter material
PE
Housing material
Die-cast zinc
Material of bowl
PC
