Size Midi
Type code LF
Series D
Mounting position Vertical
Grade of filtration 5 µm
Condensate drain Fully automatic
Max. condensate volume 43 ml
Bowl guard Metal bowl guard
Symbol 00991520
Operating pressure 2 bar ... 12 bar
Standard nominal flow rate 1800 l/min
Corrosion resistance class (CRC) 2 - Moderate corrosion stress
Storage temperature -10 °C ... 60 °C
Temperature of medium 5 °C ... 60 °C
Ambient temperature 5 °C ... 60 °C
Pneumatic connection 1 3/8 NPT
Pneumatic connection 2 3/8 NPT
Note on materials RoHS-compliant
Compressed air filter material PE
Housing material Die-cast zinc
Material of bowl PC
