FESTO VSVA-B-M52-AH-A1-1R2L Air Solenoid Valve 534535 Width 26mm

Valve function 5/2, monostable
Lap Overlap
Actuation type Electrical
Width 26 mm
Pneumatic working port Sub-base, size 26 mm as per ISO 15407-1
Operating voltage 24V DC
Operating pressure 3 bar ... 8 bar
Design Piston gate valve
Reset method Pneumatic spring
Degree of protection IP65 NEMA 4
Nominal width 9 mm
Width dimension 27 mm
Type code VSVA
Exhaust air function With flow control option
Via individual sub-base Via throttle plate
Sealing principle Soft
Mounting position Any
Type of control Pilot-controlled
Pilot air supply port Internal
Flow direction Non-reversible
Symbol 00991049
Signal status display LED
b-value 0.25
C value 4.5 l/sbar
Flow rate of pneumatic valve 1400 l/min
Flow rate of pneumatic valve on individual sub-base 1100 l/min
Optimized flow rate of pneumatic valve pneumatically concatenated flow 1100 l/min
Switching time off 40 ms
On switching time 25 ms
Duty cycle 100%
Max. positive test pulse with 0 signal 500 µs
Max. negative test pulse on 1 signal 500 µs
Nominal pick-up current per solenoid coil 110 mA to 20 ms
Nominal current with current reduction 30 mA after 20 ms
Coil characteristics 24 V DC: low-current phase 1.0 W, high-current phase 2.4 W
Permissible voltage fluctuations +/- 10 %
